TRACO POWER TDL21222 DC-DC Converter
The TDL 2 series from TracoPower offers compact, reliable 2W DC/DC converters with wide input voltage ranges of 5V, 12V, 24V, or 48V DC, suitable for industrial and automation applications. They feature regulated output voltages like 3.3V, 5V, 12V, 15V, and bipolar options such as ±5V, ±12V, and ±15V, with output currents from 67mA to 400mA. These converters operate at a switching frequency of at least 100kHz, providing efficiencies up to 87%, low ripple (~70mVp-p), and built-in short circuit protection with automatic recovery. They offer high input/output isolation of 1500VDC, ensuring safety and noise immunity, and meet stringent safety standards including UL 60950-1 and IEC/EN 60950-1. Operating reliably from -40°C to 70°C, they include a three-year warranty, making them ideal for demanding electronic systems requiring compact, safe, and efficient power conversion.
TRACO POWER TDL21222 DC-DC Converter Specifications:
- Input Voltage Range: 5VDC, 12VDC, 24VDC, 48VDC
- Output Voltage Options: 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V
- Output Current: 67mA to 400mA depending on model
- Efficiency: Up to 87%
- Ripple and Noise: approximately 70mVp-p at 20 MHz bandwidth
- Isolation Voltage: 1500VDC for 60 seconds
- Operates in temperature range: -40°C to +70°C
- Switching Frequency: ≥100kHz
- Protection: Short circuit with automatic recovery
- Compliance: UL 60950-1, IEC/EN 60950-1
- Physical: Compact DIP package, 0.55 x 0.55 x 0.31 inches
- Reliability: MTBF over 4 million hours
- Environmental: Withstands up to 95% humidity (non-condensing)
Buy the Traco Power Series TDL 2 DC-DC Converter: TDL21222
Purchase the Traco Power TDL21222 DC-DC converter online today for high-efficiency power regulation. Designed for industrial and automation use, it offers a compact DIP package, high isolation of 1500VDC, and a wide input voltage range. Enjoy low ripple noise, built-in short circuit protection, and compliance with UL and IEC safety standards. With operating temperatures from -40°C to 70°C, this reliable converter is perfect for demanding applications needing stable, safe power conversion. Buy now and ensure optimal performance in your projects.
Buy Traco Power TDL21222 now and experience unmatched power conversion efficiency and safety for your electronic systems.
Frequently Asked Questions
Where can I buy TRACO POWER TDL21222?
You can click on the BUY or RFQ button to purchase TDL21222 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TDL21222?
You can download the TDL21222 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TDL21222?
TRACO POWER
