TRACO POWER THN154825N DC-DC Converter
The THN 15N series is a compact 15 Watt DC/DC converter designed for space-constrained industrial and communication applications. Encapsulated in a 1” x 1” x 0.4” metal package, it offers a wide input voltage range of 9-36 VDC and up to 91% efficiency. Features include an internal EN 55032 class A filter, remote On/Off, output trimming, overload, overvoltage, and short circuit protection. Operating temperature extends from -40°C to +70°C, making it suitable for diverse environments. Designed with high reliability, it complies with UL 62368-1 safety standards and supports distributed power architectures in industrial electronics.
TRACO POWER THN154825N DC-DC Converter Specifications:
- Power: 15 Watt
- Input Voltage Range: 9-36 VDC
- Output Voltage: 3.3 V, 5 V, 12 V, 15 V, 24 V, +5 V, +12 V, +15 V, +24 V (adjustable 10-20%)
- Maximum Output Current: 500 mA to 4500 mA depending on model
- Efficiency: Up to 91%
- Operating Temperature: -40°C to +70°C
- Isolation Voltage: 1600 VDC
- Ripple and Noise: 75-125 mVp-p depending on model
- Dimensions: 1” x 1” x 0.4”, copper casing, weight approximately 16.6 g
- Input filter: Internal Pi type
- Switching Frequency: 220-330 kHz
- Protections: Overload, overvoltage, short circuit
- MTBF: 1,670,000 hours at 25°C
- Humidity: 5-95% relH
- Certifications: UL 62368-1, EN 55032, EN 55011
Buy the Traco Power THN 15N – Reliable DC-DC Converter for Industrial Applications
Discover the high-performance THN 15N series DC-DC converter, offering 15 Watts of reliable power with a wide 9-36 VDC input range and efficiencies up to 91%. Its compact, rugged metal package ensures durability in demanding industrial environments. Features include internal filters, remote On/Off, output trimming, and comprehensive protection against overload, overvoltage, and short circuits. Operating seamlessly from -40°C to +70°C, it supports distributed power architectures and advanced safety standards, making it ideal for mobile equipment, instrumentation, and space-critical applications. Purchase online now for fast delivery and trusted quality.
Order your Traco Power THN 15N series 15 Watt DC-DC converter today and give your industrial and communication projects the dependable power solution they deserve.
Frequently Asked Questions
Where can I buy TRACO POWER THN154825N?
You can click on the BUY or RFQ button to purchase THN154825N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN154825N?
You can download the THN154825N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN154825N?
TRACO POWER
