TRACO POWER THN154810N DC/DC Converter
The THN 15N series is a high-performance 15 Watt DC/DC converter encased in a compact 1” x 1” x 0.4” metal package, featuring EN 55032 class A filter and operating efficiently from -40°C to +70°C without derating. It offers a wide 2:1 input voltage range with voltages from 9-36 VDC, precise regulation, and remote On/Off control. Designed for space-constrained applications, it provides overload, overvoltage, and short circuit protection with up to 91% efficiency, ideal for industrial, communication, and instrumentation uses, supported by a 3-year warranty.
TRACO POWER THN154810N DC/DC Converter Specifications:
- Power: 15 Watt
- Input Voltage Range: 9-36 VDC (wide 2:1 ratio)
- Output Voltage: 3.3 V, 5 V, 12 V, 15 V, 24 V, +5 V, +12 V, +15 V, +24 V (adjustable 10-20%)
- Output Current: 315 mA to 4.5 A depending on model
- Efficiency: Up to 91%
- Operating Temperature Range: -40°C to +70°C without derating
- Isolation Voltage: 1600 VDC
- Physical Dimensions: 1” x 1” x 0.4” (25.4 mm x 25.4 mm x 10.16 mm)
- Protection: Overload, overvoltage, short circuit
- Remote On/Off Control: Yes
- Input Filter: Internal Pi type
- Switching Frequency: 220-270 kHz
- Thermal Impedance: 17 K/W
- Certifications: UL 62368-1, EN 55032, EN 55011 class A
- Isolation Resistance: 1 GΩ min.
- MTBF: 1,670,000 hours
Buy the Traco Power Series THN 15N DC/DC Converter: THN154810N
Purchase the Traco Power THN 15N series 15 Watt DC/DC converter online for maximum efficiency and space-saving design. This compact, encapsulated module features wide input voltage range from 9V to 36V, high efficiency up to 91%, and comprehensive protection against overloads and short circuits. Ideal for industrial electronics, communication systems, and instrumentation, it operates seamlessly from -40°C to +70°C without derating, ensuring reliable performance. Supported by a 3-year warranty, it is your trusted choice for advanced power solutions in space-constrained applications.
Order your Traco Power THN 15N series 15 Watt DC/DC converter today and ensure reliable power regulation in your industrial or communication projects.
Frequently Asked Questions
Where can I buy TRACO POWER THN154810N?
You can click on the BUY or RFQ button to purchase THN154810N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN154810N?
You can download the THN154810N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN154810N?
TRACO POWER
