TRACO POWER TDL31223 DC/DC converter
The TDL 3 series from TracoPower consists of 3W single and dual output DC/DC converters. These compact modules feature a wide 2:1 input voltage range, available in nominal inputs of 5VDC, 12VDC, 24VDC, and 48VDC. They provide regulated output voltages including 3.3VDC, 5VDC, 12VDC, 15VDC, as well as ±5VDC, ±12VDC, and ±15VDC, with maximum output currents ranging from 100mA to 600mA. Designed with high efficiency up to 87% and operating switching frequencies of at least 100kHz, these converters include continuous, automatic recovery short circuit and overload protection. They offer high isolation with 1500VDC I/O isolation voltage (60 seconds), typical I/O capacitance of 100pF, and resistance exceeding 1 GΩ. The ripple and noise at 20MHz bandwidth is typically 70mVp-p. Approved under UL 60950-1 and IEC/EN 60950-1 safety standards, they operate in temperatures from -40°C to 70°C and come with a 3-year warranty.
TRACO POWER TDL31223 DC/DC converter Specifications:
- Power: 3W maximum output power
- Input Voltage Range: 4.5 - 9 VDC, 9 - 18 VDC, 18 - 36 VDC, 36 - 75 VDC (wide 2:1 range)
- Output Voltages: 3.3VDC, 5VDC, 12VDC, 15VDC, ±5VDC, ±12VDC, ±15VDC
- Maximum Output Current: 100mA to 600mA depending on model
- Efficiency: up to 87%
- Switching Frequency: ≥100kHz
- Isolation Voltage: 1500 VDC (input/output, 60 sec)
- Ripple & Noise: 70mVp-p at 20MHz bandwidth
- Operating Temperature: -40°C to +70°C (derating above 70°C)
- Short Circuit Protection: Yes, automatic recovery
- Overload Protection: At 170% of rated output, foldback
- I/O Capacitance: 100pF typical
- Design: Compact DIP package (0.55 x 0.55 x 0.31 inch)
- Safety Standards: UL 60950-1, IEC/EN 60950-1
- Humidity: Up to 95% relative humidity (non-condensing)
Buy the Traco Power Series TDL3 3W DC/DC Converter: TDL31223
Purchase the Traco Power Series TDL3 3W DC/DC converter online today and ensure your applications benefit from high efficiency, robust isolation, and reliable regulation. Designed for industrial, embedded, and automation projects, these compact modules provide stable output voltages with multiple options, excellent thermal performance, and automatic short circuit protection. With a 3-year warranty and compliance with safety standards, ordering online simplifies procurement and guarantees you receive a proven, dependable power solution tailored to demanding technical environments.
Order your Traco Power Series TDL3 3W DC/DC Converter today and give your industrial and embedded projects the reliable power they need.
Frequently Asked Questions
Where can I buy TRACO POWER TDL31223?
You can click on the BUY or RFQ button to purchase TDL31223 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TDL31223?
You can download the TDL31223 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TDL31223?
TRACO POWER
