TRACO POWER THN151212 DC/DC Converter Module
The THN 15 Series is a high-performance 15W DC/DC converter module designed for space-constrained applications. Encapsulated in a compact 1.0” x 1.0” x 0.4” shielded metal case with an isolated baseplate, it features a wide 2:1 input voltage range, high efficiency up to 88%, and a temperature range from -40°C to +85°C. Suitable for industrial electronics, communication systems, and instrumentation, it offers remote on/off control, output trimming, and robust safety standards, making it ideal for demanding environments requiring reliable, high-density power solutions.
TRACO POWER THN151212 DC/DC Converter Module Specifications:
- Power: 15W
- Dimensions: 1.0” x 1.0” x 0.4” (25.4 mm x 25.4 mm x 10.16 mm)
- Input Voltage Range: 9-36 VDC or 18-75 VDC depending on model
- Input Current at No Load: 20-120 mA depending on model
- Input Current at Full Load: 330-1550 mA depending on model
- Input Surge Voltage: 36V to 100V max.
- Output Voltage: 3.3V, 5V, 9-18V, 12V, 15V, +5V, +12V, +15V
- Output Current: 500mA to 4000mA depending on model
- Efficiency: Up to 89%
- Output Ripple and Noise: 100mVpk-pk max.
- Protection: Overvoltage, short circuit, foldback current limiting
- Isolation Voltage: 1500VDC
- Operating Temperature: -40°C to +85°C (with derating)
- Storage Temperature: -55°C to +125°C
- Case Material: Nickel-coated copper
- Potting Material: Epoxy (UL 94V-0 rated)
- Soldering Temperature: Max. 265°C / 10 sec.
- Reliability: MTBF > 560,000 hours
- Switching Frequency: 400 kHz
- Product Certification: UL / cUL 60950-1, EN 60950-1, IEC 60950-1
- Isolation Resistance: >1 GOhm at 500VDC
- Thermal Impedance: 18.2°C/W natural convection
- Weight: 15 g
Buy the TracoPower Series THN151212 DC/DC Converter Module: 15W
Enhance your electronic system with the TracoPower THN 15 Series DC/DC converter, offering a compact design, high efficiency up to 89%, and wide input voltage range. Perfect for industrial, communication, and instrumentation applications where space is limited, this 15W module features excellent thermal performance, reliable protection, and compliance with international safety standards. Easy to integrate with remote on/off control and robust construction, it ensures stable power delivery, reducing system downtime and optimizing performance in demanding environments.
Order your TracoPower THN 15 Series 15 Watt converter today and experience the space-saving, high-efficiency power solution vital for your industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER THN151212?
You can click on the BUY or RFQ button to purchase THN151212 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN151212?
You can download the THN151212 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN151212?
TRACO POWER
