TRACO POWER TEA10505E DC/DC Converter
The TEA 1E Series is a compact, efficient 1 Watt DC/DC converter with a SIP-7 package, ideal for space-constrained industrial applications. It offers isolation of 1500 VDC, operates from -40°C to +95°C, with an efficiency up to 78%. Designed for high-volume use, it features unregulated output, a broad input voltage range of 4.5-5.5 VDC, and robust safety standards. Using simple, cost-effective design and automatic manufacturing, this converter provides reliable performance for industrial, automation, and control systems needing low power, high isolation, and durability.
TRACO POWER TEA10505E DC/DC Converter Specifications:
- Input Voltage Range: 4.5-5.5 VDC (nominal 5 VDC)
- Output Voltage: 5 VDC, unregulated
- Output Current: 200 mA
- Isolation Voltage: 1500 VDC (input to output)
- Operating Temperature Range: -40°C to +95°C
- Efficiency: Up to 78%
- Ripple and Noise: 50 mVp-p typical
- Start-up Time: 30 ms max.
- Power: 1 Watt
- Housing Material: Plastic UL 94 V-0 rated
- Dimensions: approximately 20.3 mm x 6.35 mm x 9.5 mm
- Protection: Limited short circuit, internal fuse recommendation 500 mA slow blow
- Insulation Resistance: >17 MΩ at 500 VDC
- Certification Standards: EN 60950-1 (design, no certification)
Buy the Traco Power TEA 1E – Reliable DC/DC Converter for Industrial Applications
Purchase the Traco Power TEA 1E series online today and enhance your industrial systems with a compact, efficient 1 Watt DC/DC converter. Its high isolation of 1500 VDC, operating temperature from -40°C to 95°C, and efficiency up to 78% ensure dependable performance. Designed for cost-sensitive, space-constrained applications, it is perfect for automation, control panels, and critical electronics. Enjoy quick delivery, reliable quality, and seamless integration for your high-volume manufacturing needs by ordering online now.
Buy Traco Power TEA 1E now and experience unmatched reliability and performance in your industrial, automation, or control projects.
