TRACO POWER TML20215C Power Supply Module
The TML20215C is a compact encapsulated AC/DC power supply providing +15V DC at 667 mA, designed for space-critical industrial and commercial electronic applications. This module features universal input voltage 90-264 VAC, 47-440 Hz, and meets EMI standards EN 55022 class B and FCC level B. It offers protections including short circuit, overload, and overtemperature (for TML 40 models). Suitable for PCB or chassis mounting with screw terminals or solder pins, it ensures reliable power delivery with high efficiency and safety compliance, making it an ideal solution for industrial automation and control systems.
TRACO POWER TML20215C Power Supply Module Specifications:
- Input Voltage Range: 90-264 VAC, 47-440 Hz
- Output Voltage: +15V DC
- Output Current: 667 mA
- Power: 10 W
- Efficiency: 85-90%
- Protections: Short circuit, overload, overtemperature (TML 40 models)
- Isolation Voltage: 3000 VAC
- Operating Temperature: 25°C to +60°C, derating above 50°C at 3.0%/K
- Case Material: Plastic resin + fiberglass, UL 94V-0 rated
- Dimensions: 46.0 mm x 27.8 mm x 20 mm (PCB mount), 50 mm x 33 mm x 20 mm (chassis mount)
- Weight: 155 g (chassis mount), 110 g (PCB mount)
- EMI/EMC Standards: EN 55022 class B, FCC part 15, level B
- Safety Certifications: UL 60950-1, IEC 60950-1, EN 60950-1
- Leakage Current: 0.75 mA max.
- MTBF: >200,000 hours.
Buy the TracoPower TML20215C – Reliable Power Supply for Industrial Applications
Order the TracoPower TML20215C online today and enhance your project’s reliability with this high-efficiency, compact power module. It offers a stable +15V output at 667 mA, suitable for various industrial and commercial applications. With universal input voltage 90-264 VAC and protections including short circuit, overload, and overtemperature, this module guarantees safe, dependable operation. Its compliance with EMI standards and safety certifications ensures worldwide usability. Invest in this durable power supply and optimize your electronic systems for maximum performance and safety.
Buy TracoPower TML20215C now and experience unmatched reliability and performance in your industrial electronics projects.
