TRACO POWER TME0515S Miniature Isolated DC/DC Converter
The TME Series is a compact, high-efficiency, 1-watt isolated DC/DC converter in a SIP package requiring only 0.7 cm² of board space. Designed with industry-standard pinout and full SMD compatibility, it supports operating temperatures from -40°C to +85°C. Suitable for generating isolated voltages in space-constrained applications, it features 1000 VDC input/output isolation, low ripple, and excellent reliability with a minimum MTTF of over 2 million hours. These industrial-grade converters are ROHS compliant with a 3-year warranty, ideal for versatile power supply solutions.
TRACO POWER TME0515S Miniature Isolated DC/DC Converter Specifications:
- Input Voltage Range: 3.3V, 5V, 12V, 24V models
- Output Voltage: 3.3V, 5V, 9V, 12V, 15V, 24V
- Output Current Max: 260mA for 3.3V/5V models, 84mA for 12V/15V/24V outputs
- Isolation Voltage: 1000 VDC (Input/Output)
- Efficiency: up to 80%
- Operating Temperature: -40°C to +85°C
- Ripple and Noise: 150mVp-p (20 MHz bandwidth)
- Humidity: 95% rel. H (non-condensing)
- Dimensions: Compact SIP package, 1.3g - 1.7g depending on model
- Switching Frequency: 50-110 kHz
- Isolation Resistance: >1,000 Mohm
- Storage Temperature: -50°C to +125°C
- Soldering Temperature: Max 265°C for 10 seconds
- Mechanical: Non-conductive UL 94V-0 rated plastic case
Buy the TRACO Series TME 1 Watt DC/DC Converter: TME0515S
Enhance your power management with the TRACO Series TME 0515S 1-watt isolated DC/DC converter, featuring 1000 VDC isolation, high efficiency up to 80%, and a compact SIP package design. Perfect for space-constrained industrial applications, it offers reliable performance across a wide temperature range from -40°C to +85°C. With ROHS compliance, a 3-year warranty, and full SMD design, this converter ensures long-term durability and consistent power supply for your electronics. Order now for fast online delivery and improve your device's power stability today.
Order your TRACO Series TME 0515S compact 1-watt isolated DC/DC converter today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy TRACO POWER TME0515S?
You can click on the BUY or RFQ button to purchase TME0515S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME0515S?
You can download the TME0515S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME0515S?
TRACO POWER
