TRACO POWER TBL015112 Industrial Power Supply
The power supply unit is designed for industrial applications, providing a reliable DC output with adjustable voltage range from 30V to 52V, depending on model. It features robust input voltage compatibility of 85-264VAC, high efficiency, and built-in protections including class 120 protection and overload safeguards. Mountable on 35mm DIN rails, it ensures optimal cooling and is suitable for clean, dry environments. Internal fuses are non-accessible, requiring professional handling for maintenance or fuse replacement. Ideal for automation and control systems, it guarantees stable power with safety compliance.
TRACO POWER TBL015112 Industrial Power Supply Specifications:
- Nominal input voltage: 85-264VAC
- Input voltage frequency range: 47-63Hz
- Inrush current: 15/30A (115/230VAC)
- Output power: 75W
- Output voltage adjustment range: 30-52V
- Maximum output current: 2A
- Efficiency: 73-77% depending on model
- Operating temperature: -25°C to +70°C
- Power derating: 2.5%/K above 60°C
- Input power derating: 5.96V/100VAC below 90VAC
- Protection class: Class 120
- Degree of protection: IP20
- Leakage current: Max 0.25mA
- Mounting: DIN rail compatible (35mm DIN standard)
- Enclosure: Enclosed in plastic case, mounted in a dry environment
- Cooling: Adequate ventilation required, ensures safe operation
- Fuses: Internal fuse not accessible, factory sealed for safety
Buy the Traco Power Series Power Supply: TBL015112
Order the Traco Power Series TBL015112 industrial power supply online today and ensure a stable, efficient power source for your automation and control systems. Its adjustable output voltage from 30V to 52V, high efficiency, and reliable protection features make it ideal for demanding industrial environments. Easy to mount on DIN rails with compliance to safety standards, this unit provides secure connections with proper fusing and cooling. Purchase now and enjoy quick delivery, expert support, and peace of mind for your power management needs.
Get Traco Power Series TBL015112 today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy TRACO POWER TBL015112?
You can click on the BUY or RFQ button to purchase TBL015112 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TBL015112?
You can download the TBL015112 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TBL015112?
TRACO POWER
