TRACO POWER TMH2415D Miniature DC/DC Converter
The TMH series consists of ultra-miniature, 2 Watt isolated DC/DC converters in a single-in-line package, ideal for space-critical applications. Features include industry-standard pinout, high efficiency up to 83%, and RoHS compliance. They support single and dual outputs with 1/0 isolation of 11,000 VDC. The converters are fully SMD-designed, require only 1.5 cm2 board space, and undergo 8 hours of burn-in testing to ensure reliability. Suitable for board-level power distribution in compact electronic systems, these converters offer excellent performance at a low cost.
TRACO POWER TMH2415D Miniature DC/DC Converter Specifications:
- Input Voltage: 5 VDC, 12 VDC, 24 VDC models
- Output Voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Current Max: 400 mA (5V), 165 mA (12V), 130 mA (15V), 200 mA (dual outputs)
- Efficiency: Up to 83%
- Isolation Voltage: 11,000 VDC for 1/0 isolation
- Surge Voltage (1 sec): 9 V (5V models), 18 V (12V models), 30 V (24V models)
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature: -40°C to +125°C
- Humidity: 95% relative humidity, non-condensing
- Dimensions: Approximately 19.5 mm x 10.25 mm x 11.2 mm
- Weight: 27 g
- Materials: Non-conductive black plastic casing, UL 94.V0 rated
- Soldering Max Temperature: +265°C / 10 seconds
- Isolation Resistance: >1000 MΩ
- MTBF: >2,000,000 hours
Buy the Buy TRAC’ Power TMH Series 2 Watt Part Number TMH2415D Online
Purchase the TRAC’ Power TMH2415D miniature 2 Watt isolated DC/DC converter online today. This compact, high-performance power module delivers up to 83% efficiency, supporting both single and dual outputs with 11,000 VDC isolation. Its SMD design requires only 1.5 cm2 on your PCB, ideal for space-constrained systems. Built with RoHS compliance and undergoes burn-in testing for long-term reliability. Enhance your electronic designs by ordering now for dependable voltage regulation in industrial, medical, and communication equipment.
Order your TRAC’ Power TMH2415D series reliable 2 Watt DC/DC converter today and enhance your electronic projects with high efficiency and robust isolation.
Frequently Asked Questions
Where can I buy TRACO POWER TMH2415D?
You can click on the BUY or RFQ button to purchase TMH2415D from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMH2415D?
You can download the TMH2415D datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMH2415D?
TRACO POWER
