TRACO POWER TMR62413WIR DC/DC Converter
The TMR 6WIR series comprises compact, high-efficiency 6 Watt DC/DC converters in a SIP-8 metal case, designed for railway, industrial, and automation applications. They operate within a wide input voltage range (4:1 ratio), with EN 50155 railway approval, UL certification, and protective features such as overload and short circuit protection. Capable of operating at -40°C to +80°C with derating, these fully regulated converters include optional remote On/Off, 3000 VDC isolation, and low no-load input current, making them versatile for space-constrained environments.
TRACO POWER TMR62413WIR DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC or 43-160 VDC
- Output Voltage Options: 3.3 V, 5 V, 9 V, 15 V, 24 V, ±5 V, ±12 V, ±15 V
- Maximum Output Current: 250 mA to 1500 mA depending on model
- Efficiency: Up to 88%
- Operating Temperature: -40°C to +80°C with derating above 60°C at 2.5%/K
- Isolation Voltage (input to output): 3000 VDC, (input/output to case): 1500 VDC
- Ripple & Noise: 20 MHz bandwidth, up to 175 mVp-p
- Protections: Overload, short circuit, automatic recovery
- Switching Frequency: Approx. 580 kHz
- Enclosure: Copper case, silicone potting (UL94 V-0)
- Dimensions: Compact SIP-8 case, details vary per model
- Certifications: EN 50155, UL 60950-1, IEC/EN/UL 60950-1
- Compliance: RoHS, EN 61000-4 series immunity standards
Buy the Traco Power TMR62413WIR – Reliable Industrial DC/DC Converter for Rail Applications
Discover the compact, high-efficiency DC/DC converter designed for demanding industrial environments. With EN 50155 railway approval, 3000 VDC isolation, and wide input voltage range, it ensures reliable power conversion. Suitable for space-limited applications, it features overload and short circuit protection, operating from -40°C to +80°C with derating. Its rugged construction and low-no load input current make it ideal for automation, transportation, and industrial systems. Order online now and enhance your project’s reliability with this proven, certified power solution.
Order your Traco Power TMR 6WIR Series 62413WIR today and give your industrial projects the dependable quality they deserve with proven railway approval.
Frequently Asked Questions
Where can I buy TRACO POWER TMR62413WIR?
You can click on the BUY or RFQ button to purchase TMR62413WIR from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR62413WIR?
You can download the TMR62413WIR datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR62413WIR?
TRACO POWER
