TRACO POWER TEN34811N DC-DC Converter
The TEN 3-4811N from TracoPower is a 3W single-output DC to DC converter in a 24-pin DIP package. It serves as a drop-in replacement for the popular TEN 3 series, featuring an updated design that reduces costs without compromising reliability or functionality. This converter supports a wide input voltage range of 36VDC to 75VDC, with an input current of approximately 15mA at no load. It provides a stable 5VDC output with a maximum current of 600mA and an efficiency of 81%, ensuring high reliability with an MTBF exceeding 1 million hours. The device measures 20.3mm x 10.2mm x 31.8mm and operates over an extended temperature range from -40°C to +85°C. It includes comprehensive electromagnetic compatibility (EMC) features meeting EN 55022, class A, and FCC level A standards without requiring external components. The converter offers continuous, automatic short-circuit protection, no minimum load requirement, and complies with various safety standards such as IEC 60950-1 and UL 60950-1. It features robust input/output isolation of 1500VDC, a start-up voltage of 36VDC or lower, and a maximum surge voltage of 100V for up to 1 second. The product is suitable for power management and industrial applications, equipped with high EMC immunity and reliable performance in demanding environments.
TRACO POWER TEN34811N DC-DC Converter Specifications:
- Power Output: 3W
- Input Voltage Range: 36VDC to 75VDC
- Output Voltage: 5VDC
- Output Current: Max 600mA
- Efficiency: 81%
- Operating Temperature: -40°C to +85°C
- MTBF: >1 million hours
- Isolation Voltage: 1500VDC
- Surge Voltage (1 sec.): 100V max.
- Start-up Voltage: 36VDC or lower
- Ripple and Noise: 70 mVpk-pk (20 MHz bandwidth)
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Operating Humidity: 95% rel H max.
- Safety Standards: IEC 60950-1, UL 60950-1
- EMC Compliance: EN 55022, FCC level A
- Short Circuit Protection: Yes, automatic recovery
- Pin Material: Copper alloy, gold plated
Buy the Buy TracoPower TEN 3-4811N Part Number TEN34811N Online
Order the TracoPower TEN 3-4811N online today to ensure reliable power conversion with high efficiency, extended temperature range, and robust EMC compliance. This 3W converter supports a wide input voltage range, delivers a stable 5V output at up to 600mA, and features comprehensive safety and EMC measures. Ideal for industrial applications, power management, and demanding environments, it offers automatic short-circuit protection, high isolation voltage, and MTBF exceeding 1 million hours. Buy now to enhance your power design with trusted quality.
Buy TracoPower TEN 3-4811N now and experience unmatched reliability and performance in industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34811N?
You can click on the BUY or RFQ button to purchase TEN34811N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34811N?
You can download the TEN34811N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34811N?
TRACO POWER
