TRACO POWER TEL124811WI DC/DC Converter
The TEL 12WI series from Traco Power offers a 12-watt DC/DC converter in an ultra-compact DIP-16 metal package, featuring high power density of 3.61 W/cm³, a wide 4:1 input voltage range, and efficiencies up to 88%. Designed for space-critical industrial applications, it operates in temperatures from -40°C to +88°C, includes an internal EMI filter, and provides protection against shorts with automatic recovery. Ideal for instrumentation, IT, and industrial electronics, this series ensures reliable performance with a 3-year warranty.
TRACO POWER TEL124811WI DC/DC Converter Specifications:
- Power: 12 Watts
- Input Voltage Range: 5.1 VDC to 48 VDC (wide 4:1 range)
- Output Power: Single and dual outputs, up to ±15 VDC
- Efficiency: Up to 88%
- Operating Temperature: -40°C to +88°C
- Isolation Voltage: 1600 VDC (input to output)
- Isolation Resistance: 17000 MΩ
- Common Mode Transient Immunity: EN 61000-4-6, 10 Vrms
- Ripple and Noise: 70 mVp-p (20 MHz bandwidth)
- Protection: Short circuit, automatic recovery
- Reliability: MTBF 2,314,000 hours
- Housing Material: Aluminum alloy, black anodized
- Soldering Profile: Wave soldering at 260°C for 10 seconds
- Dimensions: Approx. 23.8 mm x 15.24 mm x 10 mm
- Weight: 8.6 grams
Buy the Traco Power TEL 12WI – Reliable DC-DC Converter for Industrial Applications
Purchase the Traco Power TEL 12WI series online today and experience a reliable, high-efficiency 12-watt DC/DC converter designed for industrial, instrumentation, and IT applications. Its compact metal casing, wide input voltage range, and EMI filtering make it an ideal choice for space-critical environments. With a 3-year warranty, automatic short circuit recovery, and proven durability, this converter ensures seamless operation and exceptional performance in demanding settings. Order now to secure a dependable power solution for your industrial needs.
Get Traco Power TEL 12WI today—built for precision and long-lasting durability in industrial electronics.
Frequently Asked Questions
Where can I buy TRACO POWER TEL124811WI?
You can click on the BUY or RFQ button to purchase TEL124811WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL124811WI?
You can download the TEL124811WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL124811WI?
TRACO POWER
