TRACO POWER TEN34822WI DC-DC Converter Module
The TEN 3WI series from TracoPower consists of 3W single and dual output DC-to-DC converters housed in a 24-pin DIP package. These converters feature a wide 4:1 input voltage range with typical inputs of 24VDC and 48VDC. They provide multiple output voltages including 3.3V, 5V, 12V, 15V, and bipolar options of ±12V and ±15V, with maximum output currents ranging from 200mA to 750mA. The converters offer high efficiency up to 84%, supporting an operating temperature range from -40°C to +70°C at full load. They operate at a PWM switching frequency of approximately 350kHz and provide 1500VDC I/O isolation voltage for 60 seconds. Additional features include automatic recovery short-circuit protection, current limiting, internal filtering compliant with EN 55022-A and FCC Level A standards, and ripple/noise levels up to 75mV peak-to-peak at 20MHz bandwidth. Certified under cUL/UL 60950-1 and IEC/EN 60950-1 safety standards, these compact converters measure 20.3mm x 10.2mm x 31.8mm and come with a 3-year warranty. Ideal applications include battery-operated equipment, communication systems, instrumentation, and industrial electronics needing isolated and regulated power.
TRACO POWER TEN34822WI DC-DC Converter Module Specifications:
- Input Voltage Range: 9-36VDC or 18-75VDC
- Output Voltages: 3.3V, 5V, 12V, 15V, ±12V, ±15V
- Output Currents: up to 750mA
- Maximum Efficiency: 84%
- Isolation Voltage: 1500 VDC for 60 seconds
- Operating Temperature: -40°C to +70°C full load
- Switching Frequency: approx. 350 kHz
- Ripple and Noise: up to 75mV peak-to-peak at 20MHz bandwidth
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Certifications: UL 60950-1, IEC/EN 60950-1
- Protection Features: automatic short-circuit recovery, overload, overvoltage
- Input Filter: complies with EN 55022-A, FCC Level A standards
- Weight: 12g
- Soldering Temperature Max: 265°C / 10 sec.
Buy the TracoPower Series TEN 3WI DC-DC Converter: TEN34822WI
Purchase the TracoPower TEN34822WI DC-DC converter online today for reliable power regulation in demanding industrial, communication, and battery-powered applications. This 3W module delivers high efficiency up to 84%, wide input voltage range, and strong isolation, ensuring safe and stable operation across temperatures from -40°C to +70°C. Its compact size, certified safety standards, robust short-circuit protection, and internal EMI filter make it perfect for sensitive electronic systems needing precise, isolated power. Elevate your project with proven quality—order now and experience dependable power conversion.
Get TracoPower TEN34822WI today—compact, highly efficient, and ideal for industrial and communication power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34822WI?
You can click on the BUY or RFQ button to purchase TEN34822WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34822WI?
You can download the TEN34822WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34822WI?
TRACO POWER
