TRACO POWER THM204822WI Medical Power Converter
The THM 20WI series offers 20-watt medical-grade DC/DC power converters with ultra-wide 4:1 input voltage range, high efficiency up to 89%, reinforced 5000 VACrms isolation, and low leakage current below 2.5 pA. Designed for medical and demanding industrial use, they operate reliably from -40°C to +80°C, are compliant with IEC 60601-1 standards, and feature low noise, high safety, and robust thermal performance. Suitable for transportation, control, measurement, and IGBT driver applications with extended altitude and temperature capabilities.
TRACO POWER THM204822WI Medical Power Converter Specifications:
- Power Output: 20 Watts
- Input Voltage Range: 9V to 36V DC (Model THM 20-2413WI) / 48V DC (Models THM 20-481xWI)
- Output Voltage Options: 5V, 12V, 15V, 24V DC
- Maximum Output Current: 2000mA for 5V, 833mA for 12V, 667mA for 15V, 833mA for 24V
- Efficiency: Up to 89.5%
- Isolation Voltage: 5000 VACrms
- Leakage Current: < 2.5 pA
- Operating Temperature Range: -40°C to +80°C
- Humidity: 5% to 95% RH non-condensing
- Altitude: Up to 5000 m
- Dimensions: 25.4 x 25.4 x 10 mm (1.00 x 1.00 x 0.39 inch)
- Case Material: Non-conductive plastic, potting with UL94 V-0 rated silicone
- Soldering Temperature: Max 265°C for 10 seconds
- Isolation Voltage: 5000 VACrms, reinforced
- MTBF: 1,000,000 hours
- Switching Frequency: 225-285 kHz
- Compliance: IEC 60601-1, IEC 60601-1-2, RoHS, Reach
Buy the Traco Power THM204822WI – Reliable Medical DC/DC Converter for Industrial Applications
Purchase the Traco Power THM 20WI series online today to benefit from high-efficiency medical-grade DC/DC converters. Designed for demanding environments, these units offer ultra-wide input ranges, reinforced 5000 VACrms isolation, and operation from -40°C to +80°C. Suitable for medical equipment, transportation, control systems, and measurement applications, they feature low leakage current, high MTBF, and compliance with IEC standards. Order now to ensure reliable power delivery with safety, robustness, and extended operational life.
Buy Traco Power THM 20WI series DC/DC converter now and experience unmatched reliability, efficiency, and safety for demanding medical and industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER THM204822WI?
You can click on the BUY or RFQ button to purchase THM204822WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM204822WI?
You can download the THM204822WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM204822WI?
TRACO POWER
