TRACO POWER TEN32422 Dual-output Power Converter
The TEN 3-2422 is a dual-output, 3W board-mount DC/DC converter suitable for industrial power management. It operates within 18-36V DC input range and delivers ±12V DC outputs with efficiencies around 82%. Designed for robust performance, it supports -40°C to 85°C temperatures, features short-circuit protection, and offers 1500V DC input/output isolation. Built with full SMD technology, this converter ensures high reliability for industrial, communication, sensing, and instrumentation applications, guaranteeing over 1.1 million hours MTBF for long-term dependable operation.
TRACO POWER TEN32422 Dual-output Power Converter Specifications:
- Input Voltage Range: 18 to 36 V DC
- Output Voltages: ±12 V DC
- Output Power: 3 W
- Efficiency: approximately 82%
- Operating Temperature Range: -40°C to 85°C
- Isolation Voltage: 1500 VDC input/output
- Short-circuit Protection: yes
- MTBF: Greater than 1.1 million hours
- Mounting Style: Full SMD design
- Surge Voltage (max): 50 V
- Ripple and Noise: 60 mVpeak-to-peak
- Overall Dimensions: 22.86 mm x 20.32 mm x 10.16 mm
- Soldering Temperature: max 265°C for 10 seconds
- Housing Material: UL 94V-0 rated epoxy
- Switching Frequency: 300 kHz
- Certifications: UL, IEC/EN 60950-1, Reach, RoHS
Buy the Tracopower Series Power Ten: DC/DC Converter 3W: TEN32422
Purchase the Tracopower Series Power Ten TEN32422 online today and benefit from a high-efficiency, reliable dual-output power converter designed for industrial use. Featuring an input range of 18-36V DC, ±12V outputs, and over 82% efficiency, this device ensures stable power delivery with excellent thermal performance. Its full SMD design enhances durability, while short-circuit protection and 1500V input/output isolation guarantee safe operation in challenging environments. Ideal for industrial automation, communication, and sensing applications, the TEN32422 offers unmatched reliability with an MTBF exceeding 1.1 million hours, making it a dependable choice for your power management needs.
Order your Tracopower Series Power Ten TEN32422 today and equip your industrial projects with reliable, top-quality power conversion components.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32422?
You can click on the BUY or RFQ button to purchase TEN32422 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32422?
You can download the TEN32422 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32422?
TRACO POWER
