TRACO POWER THB32415 DC/DC Converter
The THB 3-2415 is a high-performance regulated DC/DC converter offering 18–36 VDC input, 24 VDC output at 125 mA, and an efficiency of 84%. It features reinforced isolation, wide input voltage ranges, and operates safely from -40°C to +85°C. The device is suitable for industrial, medical, and transportation applications, meeting safety standards such as IEC 60601-1 and IEC/EN 60950-1. Designed with high reliability, internal EMI filter, and full SMD ceramic capacitors, it ensures long-term stability and compliance with EMI and safety regulations.
TRACO POWER THB32415 DC/DC Converter Specifications:
- Input Voltage Range: 18–36 VDC
- Output Voltage: 24 VDC
- Output Current Max.: 125 mA
- Efficiency: 84%
- Operating Temperature: -40°C to +85°C
- Isolation Test Voltage: 6000 Vpk
- Leakage Current: 2 pA at 240VAC, 60Hz
- Ripple & Noise: 150 mVpk-pk
- Start-up Voltage / Under Voltage Lockout: 17 VDC / 34 VDC
- Input Filter: EN 55022 Class A
- Short Circuit Protection: Auto-recovery, continuous
- Capacitive Load: 220 pF per output
- Safety Certification: IEC 60950-1, IEC 60601-1
- Derating above 70°C: 3.3%/K
- Mechanical: Non-conductive plastic case, weighs 13 g
- Soldering Temperature: Max 265°C for 10 sec.
- Altitude Operation: Up to 5000 meters
Buy the TracoPower THB3-2415 Reliable Medical Grade Power Supply for Industrial Applications
Purchase your TracoPower THB3-2415 converter online today to ensure reliable, efficient power delivery for your industrial and medical applications. Featuring reinforced isolation, broad temperature operation, and IEC compliance, this converter guarantees safety and longevity. Ideal for transportation, medical, instrumentation, and industrial control projects, it provides stable 24V output at 125mA with high efficiency. With a robust design, internal EMI filter, and full SMD ceramic capacitors, the THB3-2415 ensures long-term operation, meeting all relevant safety standards and regulations for demanding environments.
Order your TracoPower Series THB3-2415 today and give your industrial and medical equipment the dependable power they need with high reliability and safety.
