TRACO POWER TEL81222 DC/DC Converter
The TEL 8 Series is a compact, 8 Watt isolated DC/DC converter designed for space-critical applications, offering a 2:1 input voltage range and high efficiency up to 86%. Encased in DIP-16 metal, it operates from -40°C to +80°C, with built-in input filtering compliant with EN 55032 Class A. Suitable for instrumentation, industrial electronics, and IT, it provides protected, regulated outputs with overload and short circuit protection. Its small size, reliable performance, and broad input/output options make it an ideal choice for demanding environments requiring stable power solutions.
TRACO POWER TEL81222 DC/DC Converter Specifications:
- Operating temperature range: -40°C to +80°C
- Input voltage range: 36-75 VDC or 48-36 VDC depending on model
- Output voltage options: 3.3 VDC, 5 VDC, 9-18 VDC, 12 VDC, 15 VDC, 24 VDC, +12 VDC, +15 VDC
- Output current: up to 1600 mA depending on model
- Efficiency: up to 86%
- Input filter: Built-in EN 55032 class A filter
- Isolation voltage: 1500 VDC (test voltage)
- Ripple and noise: 55 mVp-p max. (20 MHz bandwidth)
- Short circuit protection: Hiccup mode, automatic recovery
- Maximum power dissipation: 8 W
- Dimensions: DIP-16 metal casing, compact design
- Pin configuration: Standard DC/DC pinout compatible with industry norms
- Soldering temperature: Max 260°C / 10 sec.
- MTBF: 1,000,000 hours
- Certifications: IEC/EN 60950-1, UL60950-1
- Operating altitude: Up to 5000 m
- Electromagnetic Compatibility: EN 61000-4 series immunity, CE, RoHS compliant
Buy the Buy Traco Power Series TEL 8 Part Number TEL81222 Online
Experience dependable power regulation with the Traco Power TEL 8 Series TEL81222, an 8 Watt isolated DC/DC converter featuring a 2:1 input range and high efficiency of up to 86%. Its compact DIP-16 metal casing makes it ideal for tight spaces in industrial, instrumentation, and IT applications. Offers regulated outputs, built-in EN 55032 class A input filter, overload and short circuit protection, and broad temperature operation from -40°C to +80°C. Perfect for sensitive electronics requiring stable, safe power supply in harsh environments.
Order your Traco Power TEL 8 Series TEL81222 today and enjoy reliable, compact power conversion designed for demanding industrial and instrumentation projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEL81222?
You can click on the BUY or RFQ button to purchase TEL81222 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL81222?
You can download the TEL81222 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL81222?
TRACO POWER
