TRACO POWER THL104813WI DC-DC Converter
The TracoPower THL 10-4813WI is a 10W DC-DC converter from the THL 10WI series. It features a compact 1 x 1 inch metal shielded case with an isolated baseplate and meets safety standards such as UL/cUL 60950-1 and IEC/EN 60950-1. The converter operates with an input voltage range of 18VDC to 75VDC (nominal 48VDC), providing an output of 15VDC at 660mA with typical efficiency of 87%. It includes an industrial standard pinout, an ultra-wide 4:1 input voltage range, and an input filter compliant with EN 55022 Class A without external components. The device offers remote On/Off control, short circuit, and overvoltage protection, suitable for operating temperatures up to +75°C or optionally +85°C with a heatsink. Typical applications include instrumentation, distributed power architectures in communication, and industrial electronics.
TRACO POWER THL104813WI DC-DC Converter Specifications:
- Power: 10 Watts
- Input Voltage Range: 18VDC to 75VDC
- Output Voltage: 15VDC
- Output Current: 660 mA
- Efficiency: 87% typical
- Input Noise: Meets EN 55022 Class A without external components
- Isolation Voltage: 1500 VDC
- Operating Temperature: -40°C to +75°C, up to +85°C with heatsink
- Size: 1 x 1 inch (25.4 x 25.4 mm)
- Case Material: Metal shielded, UL 94V-0 epoxy potting
- Input/Output Isolation Resistance: >1 GOhm at 500 VDC
- Surge Voltage: 50V for 1 sec (24V models), 100V for 1 sec (48V models)
Buy the TracoPower Series THL DC-DC Converter: THL104813WI
Purchase the TracoPower THL 10-4813WI online today to ensure reliable power conversion for your industrial or communication electronics. This compact 10W DC-DC converter features an ultra-wide input voltage range of 18VDC to 75VDC, making it suitable for various power systems. It provides a stable 15V output at 660mA, with up to 87% efficiency, ensuring minimal energy loss. The device comes with remote On/Off control, short circuit, and overvoltage protection, and meets safety standards including UL/cUL 60950-1. Its rugged case design supports operational temperatures up to +75°C or +85°C with optional heatsink, making it ideal for demanding environments. Order now for a reliable, efficient power solution that supports instrumentation, communication architectures, and industrial electronics.
Get TracoPower THL104813WI today—built for precision and long-lasting durability with wide input range and high efficiency.
Frequently Asked Questions
Where can I buy TRACO POWER THL104813WI?
You can click on the BUY or RFQ button to purchase THL104813WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL104813WI?
You can download the THL104813WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL104813WI?
TRACO POWER
