TRACO POWER TEN31212 DC/DC Converter
The POWER TEN 3 series of DC/DC converters offers a compact, high-efficiency solution designed for industrial and communication applications. With an input range from 4 VDC to 36 VDC and output options including 5 V, 12 V, and 15 V, these converters deliver up to 250 mA of current with efficiencies reaching 84%. Featuring full SMD design, internal filtering, high reliability with MTBF over 1.1 million hours, and operating temperatures from -40°C to +85°C, they ensure robust performance with short circuit protection and high isolation voltage of 1500 VDC. Ideal for demanding environments where stability and durability are essential.
TRACO POWER TEN31212 DC/DC Converter Specifications:
- Input voltage range: 4 VDC to 36 VDC
- Output voltage options: 5 V, 12 V, 15 V, 24 V, 36 V, 48 V
- Output current max.: 250 mA
- Efficiency: up to 84%
- Isolation voltage: 1500 VDC
- Operating temperature: -40°C to +85°C
- MTBF: over 1.1 million hours
- Ripple and noise: 60 mVpk-pk (20 MHz bandwidth)
- Short circuit protection: automatic; indefinite recovery
- Input/filter compliance: EN 55022, FCC level A
- Switching frequency: 300 kHz
- Soldering temperature: max. 265°C / 10 sec.
- Weight: 12.4g
- Potting: epoxy (UL 94V-0 rated)
- Safety standards: cUL/UL 60950-1; IEC/EN 60950-1
Buy the Buy TRACOPOWER DC/DC Converter Part Number TEN31212 Online
Experience the reliable performance of our high-efficiency industrial DC/DC converter. With an input range of 4 V to 36 V, multiple output options, and an operating temperature from -40°C to +85°C, this converter is built to endure demanding conditions. Its internal filtering meets EN 55022 and FCC standards, ensuring minimal noise. The device features automatic short circuit protection, high isolation voltage of 1500 VDC, a compact epoxy potting, and a lightweight design of 12.4 grams. Ideal for industrial, communication, and automation systems requiring durable power conversion.
Get TRACOPOWER TEN31212 today—designed for high reliability, efficiency, and robust performance in industrial environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEN31212?
You can click on the BUY or RFQ button to purchase TEN31212 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN31212?
You can download the TEN31212 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN31212?
TRACO POWER
