TRACO POWER TEN32412WI DC-DC Converter Module
The TEN 3WI series from TracoPower comprises 3W single and dual output DC-DC converters housed in a 24-pin DIP package. These converters feature a wide 4:1 input voltage range, with nominal inputs of 24VDC or 48VDC. They provide various output voltages including 3.3VDC, 5VDC, 12VDC, 15VDC, and ±12VDC, ±15VDC, with maximum output currents ranging from 200mA to 750mA. The converters offer high efficiency up to 84%, enabling operation across temperatures from -40°C to +70°C at full load. They include features such as automatic short circuit protection, current limiting, and internal filtering compliant with EN 55022-A and FCC Level A standards. Key specifications include an I/O isolation voltage of 1500VDC for 60 seconds, an isolation capacitance of 380pF, and resistance greater than 1000MΩ at 500VDC. Ripple and noise are specified at a maximum of 75mV peak-to-peak within a 20MHz bandwidth. These units are approved under cUL/UL 60950-1 and IEC/EN 60950-1 safety standards. Dimensions are 20.3mm x 10.2mm x 31.8mm, with a three-year product warranty. Typical applications include battery-operated equipment, distributed power architectures in communication, instrumentation, and industrial electronics where isolated, tightly regulated voltages are required.
TRACO POWER TEN32412WI DC-DC Converter Module Specifications:
- Input Voltage Range: 9-36VDC or 18-75VDC
- Output Voltages: 3.3VDC, 5VDC, 12VDC, 15VDC, ±12VDC, ±15VDC
- Maximum Output Current: 200mA to 750mA depending on model
- Efficiency: Up to 84%
- Isolation Voltage: 1500VDC for 60 seconds
- Isolation Capacitance: 380pF
- Isolation Resistance: >1000MΩ at 500VDC
- Ripple and Noise: Max 75mV peak-to-peak at 20MHz bandwidth
- Operating Temperature: -40°C to +70°C
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Humidity: Up to 95% relative humidity (non-condensing)
- Safety Standards: UL 60950-1, IEC/EN 60950-1
- Certifications: RoHS compliant
- MTBF: >1 million hours
- Soldering Temperature: Max 265°C for 10 sec
Buy the TracoPower Series TEN 3WI DC-DC Converter: TEN32412WI
Enhance your electronic projects with the TracoPower TEN 3WI series DC-DC converters. These 3W modules feature a wide input voltage range, high efficiency up to 84%, and excellent load regulation. They are suitable for battery-powered devices, communication equipment, and industrial automation, providing isolated, regulated voltages. With built-in EMI filters complying with EN 55022-A and FCC standards, and robust short circuit and over voltage protections, these converters ensure reliable operation across temperatures from -40°C to +70°C. Order online now for fast delivery and dependable power solutions.
Buy TracoPower TEN32412WI now and experience unmatched reliability and performance in industrial power supply solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32412WI?
You can click on the BUY or RFQ button to purchase TEN32412WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32412WI?
You can download the TEN32412WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32412WI?
TRACO POWER
