TRACO POWER TSR052433 Voltage Regulator
The TSR 0.5 Series is a set of compact, highly efficient switching regulators designed for step-down voltage conversion in various electronic applications. These SIP package regulators offer efficiencies up to 97%, excellent line and load regulation, and low standby current. They operate within a temperature range of -40°C to 90°C, with over-temperature and short circuit protection for enhanced reliability. Ideal as drop-in replacements for linear regulators, these models support input voltages from 1.5V to 32V and provide output voltages between 1.5V and 15V, making them suitable for demanding power supply requirements with minimal heat dissipation.
TRACO POWER TSR052433 Voltage Regulator Specifications:
- Input Voltage Range: 1.5 VDC to 32 VDC
- Output Voltage Range: 1.5 V to 15 V
- Output Current: Up to 0.5 A
- Efficiency: Up to 97%
- Operating Temperature Range: -40°C to +90°C
- Over-temperature and Short Circuit Protection
- Ripple and Noise: 30-40 mVp-p depending on model
- Switching Frequency: 330 kHz ±50 kHz
- Dimensions: Compact SIP package, weight 1.95 g
- Certifications: UL94V-0 rated plastic case, RoHS compliant
- Isolation Voltage: None
- Reliability: MTBF > 2,000,000 hours
Buy the TracoPower Series TSR 0.5 Regulator: TSR052433
Enhance your electronic designs with the high-efficiency TracoPower Series TSR 0.5 voltage regulator, offering up to 97% efficiency, compact SIP packaging, and wide temperature operation. Its excellent line and load regulation ensure reliable power delivery for demanding applications, while additional features like over-temperature and short circuit protection improve durability and safety. Ideal for replacing linear regulators, this regulator supports input voltages up to 32V and provides stable outputs from 1.5V to 15V. Buy online today to upgrade your power supply systems with precision and confidence.
Order your TracoPower Series TSR 0.5 voltage regulator today and ensure your projects benefit from reliable, high-efficiency power conversion with excellent regulation.
Frequently Asked Questions
Where can I buy TRACO POWER TSR052433?
You can click on the BUY or RFQ button to purchase TSR052433 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TSR052433?
You can download the TSR052433 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TSR052433?
TRACO POWER
