TRACO POWER TEN32412WIN DC Power Converter
The TEN 3-2412WIN from TracoPower is a compact 3W DC-DC converter designed for reliable power conversion in industrial applications. Featuring a 4:1 ultra-wide input voltage range from 9V to 36V DC, it ensures stable output with 82% efficiency and a maximum output current of 250mA. The converter provides robust electromagnetic compatibility, meeting EN 55022 Class A and FCC Level A standards without external components. Its extended temperature range from -40°C to +85°C, high isolation voltage of 1500VDC, and safety certifications like UL 60950-1 make it ideal for demanding environments. Its compact DIP-24 package measures 20.3mm x 10.2mm x 31.8mm.
TRACO POWER TEN32412WIN DC Power Converter Specifications:
- Input voltage range: 9 VDC to 36 VDC
- Output voltage: 12 VDC
- Output current: 250 mA
- Efficiency: 82%
- Isolation voltage: 1500 VDC
- Input current no load: 30 mA at 24 V, 20 mA at 48 V
- Operating temperature: -40°C to +85°C
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Certifications: UL 60950-1, CSA, IEC/EN 60950-1
- Switching frequency: 90 kHz minimum
- Isolation resistance: >1000 MΩ at 500 VDC
- Mounting: DIP-24 package
- Protection: Automatic short circuit, no minimum load required
- Soldering temperature: 260°C for 10 seconds max
- Conforms to EMC standards EN 55022 Class A, FCC Level A
Buy the Traco Power Series TEN 3W DC-DC Converter: TEN32412WIN
Order the Traco Power TEN32412WIN today, a dependable 3W DC-DC converter offering a wide input range, high isolation voltage, and extended operating temperature. Perfect for industrial automation, power management, and demanding environments, it features UL certification, 82% efficiency, no minimum load, and automatic short circuit protection. Its compact DIP-24 form factor makes installation straightforward. Ensure reliable power conversion in your applications—buy online now to benefit from quick delivery, quality assurance, and dedicated support for your power supply needs.
Get Traco Power TEN32412WIN today—built for robust industrial power conversion with high efficiency and reliable isolation.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32412WIN?
You can click on the BUY or RFQ button to purchase TEN32412WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32412WIN?
You can download the TEN32412WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32412WIN?
TRACO POWER
