TRACO POWER THL102413 DC/DC Converter
The THL 10 series from TracoPower consists of 10W single and dual output DC/DC converters, designed for general industrial and instrumentation applications. These compact converters are housed in a 1" x 1" shielded metal case with an isolated baseplate, offering a pin-to-pin compatible replacement for 1" x 2" units. They feature a wide input voltage range (12V, 24V, or 48V DC) and various output voltages including 3.3V, 5.1V, 12V, 15V, and dual ±5V, ±12V, or ±15V options, with maximum output currents up to 2.5A. The devices provide high efficiency up to 89%, and include protections such as short circuit and overvoltage. Key specifications include a 1500V DC input-to-output isolation (measured over 60 seconds), an insulation resistance exceeding 1000 MΩ at 500V DC, and a typical ripple and noise of 80 to 100 mVp-p. Operating temperature ranges from -40°C to +80°C, extendable to +85°C with a heatsink. The series complies with safety standards UL/cUL 60950-1 and IEC/EN 60950-1, and is suitable for distributed power architectures, industrial electronics, and communication equipment.
TRACO POWER THL102413 DC/DC Converter Specifications:
- Input Voltage Range: 12V, 24V, 48V DC
- Output Voltages: 3.3V, 5.1V, 12V, 15V, ±5V, ±12V, ±15V
- Maximum Output Current: up to 2.5A
- Efficiency: up to 89%
- Isolation Voltage: 1500V DC (60 seconds)
- Insulation Resistance: >1000 MΩ at 500V DC
- Ripple and Noise: 80-100 mVp-p
- Operating Temp Range: -40°C to +80°C, up to +85°C with heatsink
- Dimensions: 1" x 1" x 0.4" (approximate)
- Protections: Short circuit, overvoltage
- Switching Frequency: 300 kHz typ.
- Certification: UL/cUL 60950-1, IEC/EN 60950-1
- Operating Altitude: up to 51,000 m
- Weight: approx. 15 g
Buy the TracoSeries DC/DC Power Converter: THL Series 10W Compact Power Supply
Purchase the TracoPower THL 10 series online today to ensure your industrial electronics and instrumentation projects benefit from reliable, efficient power. These 10W converters are housed in a compact 1" x 1" case, featuring a wide input voltage range and high efficiency up to 89%. With built-in protections and UL/cUL safety standards, they are adaptable for communication systems, industrial electronics, and distributed power architectures. Order now for fast delivery and elevate your power management solutions with proven TracoPower quality.
Buy TracoPower THL 10-xxxx now and experience unmatched reliability and high efficiency in industrial power applications.
Frequently Asked Questions
Where can I buy TRACO POWER THL102413?
You can click on the BUY or RFQ button to purchase THL102413 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL102413?
You can download the THL102413 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL102413?
TRACO POWER
