TRACO POWER TEN32415WIN DC-DC Converter
The TEN 3-2415WIN from TracoPower is a 3W single-output DC-DC converter housed in a 24-pin DIP package. It replaces the TEN 3WI series with a cost-effective, reliable design. Offering an ultra-wide 4:1 input voltage range from 9VDC to 36VDC, it delivers a fixed 24VDC output at 125mA with 81% efficiency. Featuring internal EMC filtering, it meets EN 55022, class A and FCC, level A standards without external components. The device supports operating temperatures from -40°C to +85°C, includes short circuit protection, high isolation voltage, and boasts an MTBF of over 1 million hours.
TRACO POWER TEN32415WIN DC-DC Converter Specifications:
- Input voltage range: 9VDC to 36VDC
- Output voltage: 24 VDC
- Output current max.: 125 mA
- Efficiency max.: 81%
- Isolation voltage (60 s): 1500 VDC
- Input current no load: 30 mA at 24V
- Operating temperature: -40°C to +85°C
- Humidity: up to 95% rel H, non-condensing
- MTBF: >1 million hours
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Switching frequency: min. 90kHz
- Soldering temperature: 260°C / 10 s max
- Safety standards: UL 60950-1, IEC 60950-1
- EMC compliance: EN 55022, FCC level A
- Short circuit protection: continuous, automatic recovery
- Certifications: CSA, CB, RoHS compliant
Buy the Traco Power Series TEN 3WIN DC-DC Converter: TEN 32415WIN
Order the Traco Power TEN 32415WIN 3W DC-DC converter online today to benefit from high efficiency, wide input range, reliable short circuit protection, and extended temperature range. Designed for demanding industrial and automation applications, this compact, high-reliability power module provides a consistent 24V output with no minimum load requirement. Its comprehensive EMC filtering ensures compliance with EN 55022 and FCC standards. With a proven MTBF exceeding 1 million hours, easy drop-in installation, and robust safety certifications, it is ideal for cost-critical projects requiring stable power conversion.
Buy Traco Power TEN 32415WIN now and experience unmatched reliability, high efficiency, and extended temperature operation for your challenging projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32415WIN?
You can click on the BUY or RFQ button to purchase TEN32415WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32415WIN?
You can download the TEN32415WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32415WIN?
TRACO POWER
