TRACO POWER TIM24810 Medical DC/DC Converter
This component is designed for medical applications, supporting high reliability and safety standards essential for healthcare devices.
TRACO POWER TIM24810 Medical DC/DC Converter Specifications:
- Power: 2 Watt
- Input voltage range: 3.3 VDC to 42 VDC
- Output voltage options: 3.3 VDC, 5.0 VDC, 9.0 VDC, 12 VDC, 15 VDC, 24 VDC
- Maximum output current: 500 mA
- Efficiency: up to 81%
- Isolation voltage: 5000 VAC (reinforced insulation)
- Operating temperature: -40°C to +95°C, case temperature up to 105°C
- Leakage current: less than 2 pA
- Ripple and noise: 20-50 mVp-p
- Dimensions: 14.4 x 10.16 x 7 mm, with plastic casing
- Dimensions tolerances: ±0.5 mm in length, ±0.24 mm in width
- Weight: approximately 7.09 grams
- Soldering temperature max: 260°C for 10 seconds
- Switching frequency: minimum 100 kHz
- MTBF: approximately 6,809,000 hours
Buy the Buy Traco Power DC/DC Converter TIM 2 Series 24810 Online
Purchase the Traco Power TIM 2 series 24810 online today and benefit from reliable, high-efficiency 2 Watt medical power conversion. Featuring reinforced insulation of 5000 VAC, ultra-low leakage current, and certification according to IEC 60601-1 standards, this device guarantees safety and durability. Perfect for healthcare applications, it operates over a wide temperature range, ensuring consistent performance even in demanding environments. Easy to integrate with compact dimensions and low noise, this converter is the ideal choice for medical equipment designers seeking quality and compliance. Order now to secure fast delivery and technical support.
Order your Traco Power Series TIM 2-24810 medical DC/DC converter today and ensure your healthcare devices operate with high safety and reliability.
Frequently Asked Questions
Where can I buy TRACO POWER TIM24810?
You can click on the BUY or RFQ button to purchase TIM24810 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TIM24810?
You can download the TIM24810 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TIM24810?
TRACO POWER
