TRACO POWER TEN64813N High Power DC-DC Converter
The TEN 6-4813N from Tracopower is a high-performance, single-output DC-DC converter rated at 6W, housed in a 24-pin DIP package. It is designed to provide an optimized balance of cost and performance, suitable for various applications requiring reliable power conversion. The converter features overload protection, internal filtering for EN55022 Class A compliance, no minimum load requirement, and high efficiency. Its wide input voltage range of 36VDC to 75VDC, with a startup voltage of 36VDC and surge voltage up to 100V, makes it versatile for different power environments. The output voltage is fixed at 15VDC with a maximum current of 400mA, achieving an efficiency of approximately 84%. The device provides excellent input/output isolation of 1500VDC, with high resistance and low capacitance, and is fully approved per UL/cUL 60950-1 and IEC/EN 60950-1 standards. It has a compact dimension of 20.3mm x 10.2mm x 31.8mm and can operate across a temperature range of -40°C to +85°C. Its features include continuous, automatic recovery from short circuits and a UL 94V-0 rated non-conducting plastic case with UL 94V-0 rated epoxy potting. The converter is ideal for use in distributed power architectures, workstations, computer equipment, and communication devices.
TRACO POWER TEN64813N High Power DC-DC Converter Specifications:
- Input voltage range: 36VDC to 75VDC
- Surge voltage: up to 100V max.
- Output voltage: 15VDC
- Output current: 400mA max.
- Efficiency: approximately 84%
- Isolation voltage: 1500VDC
- Operating temperature: -40°C to +85°C
- Case dimensions: 20.3mm x 10.2mm x 31.8mm
- Package: DIP-24 plastic
- Safety standards: UL/cUL 60950-1, IEC/EN 60950-1
- Conducted noise: Meets EN 55022 class A
- Soldering temperature: Max 260°C
Buy the Buy Tracopower DC-DC Converter Part Number TEN64813N Online
Secure your power management needs by purchasing the Tracopower TEN64813N online. Designed for high performance, this 6W DC-DC converter offers 15V output at 400mA, with excellent efficiency and reliability. Features include wide input voltage compatibility from 36VDC to 75VDC, UL and IEC safety standards compliance, no minimum load requirement, and exceptional input/output isolation of 1500VDC. Its compact DIP-24 case and operating temperature range of -40°C to +85°C make it suitable for demanding industrial, communication, and computing applications. Buy now for dependable power solutions.
Buy Tracopower TEN64813N now and experience reliable power conversion with high efficiency, wide input range, and robust safety features.
Frequently Asked Questions
Where can I buy TRACO POWER TEN64813N?
You can click on the BUY or RFQ button to purchase TEN64813N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN64813N?
You can download the TEN64813N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN64813N?
TRACO POWER
