TRACO POWER TEN34813WIN DC/DC Converter
The TEN 3WIN Series offers compact 3-Watt DC/DC converters with an ultra-wide input range of 4:1, extended temperature operation from -40°C to 85°C, and high reliability with MTBF over 1 million hours. Featuring internal filters to meet EN 55032 Class A without external components, these converters ensure high EMC immunity and a 3-year warranty. They are ideal for cost-sensitive, demanding applications requiring functional insulation up to 1500 VDC or 3000 VDC, with DIP-24 packages for easy drop-in replacement of existing 3W models.
TRACO POWER TEN34813WIN DC/DC Converter Specifications:
- Input voltage range: 4:1 wide input, 9V to 36V or 18V to 75V depending on model
- Output power: 3 Watts
- Output voltage options: 3.3V, 5V, 12V, 15V, 24V, ±5V, ±12V, ±15V
- Output current: up to 750mA depending on model
- Efficiency: up to 84%
- Isolation voltage: 1500 VDC or 3000 VDC (functional insulation)
- Operating temperature: -40°C to +85°C
- MTBF: >1 million hours
- Dimensions: DIP-24 package, 22.86mm x 15.24mm
- Safety standards: UL, IEC/EN 60950-1
- EMC compliance: EN 55032 Class A, EN 61000-4 series immunity
Buy the Buy Traco Power DC/DC Converter Part Number TEN34813WIN Online
Purchase the Traco Power TEN 3WIN Series TEN34813WIN online today to benefit from a high-performance 3-Watt DC/DC converter that features an ultra-wide input range, extended temperature operation, internal filters meeting EN 55032 Class A, and a 3-year warranty. Designed for cost-sensitive applications, this converter provides high efficiency up to 84%, functional insulation up to 1500 VDC, and robust reliability with an MTBF exceeding 1 million hours. Its DIP-24 package allows easy drop-in replacement in various industrial and automation setups.
Order your Traco Power TEN 3WIN Series TEN34813WIN today and ensure reliable, efficient power conversion for demanding applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34813WIN?
You can click on the BUY or RFQ button to purchase TEN34813WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34813WIN?
You can download the TEN34813WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34813WIN?
TRACO POWER
