TRACO POWER THD101212N Industrial DC/DC Converter
The THD 10 series from TracoPower consists of 10W isolated DC/DC converters in a compact DIP-24 package. They feature a wide 2:1 input voltage range, low ripple, and noise, with internal EMI filtering compliant with EN 55022, Class A. Designed for industrial electronics, instrumentation, and communication systems, these converters support input voltages of 12VDC, 24VDC, and 48VDC, with multiple output options up to 3A. They offer high efficiency up to 89%, galvanic isolation of 1500VDC, and operate reliably within -40°C to +85°C. Their robust construction and certifications make them suitable for demanding applications with limited space.
TRACO POWER THD101212N Industrial DC/DC Converter Specifications:
- Input Voltage Range: 12VDC, 24VDC, 48VDC
- Output Voltages: 3.3V, 5.1V, 12V, ±12V, ±15V
- Output Currents: up to 3A, 2A, 830mA, ±415mA, ±330mA
- Efficiency: up to 89%
- Isolation Voltage: 1500VDC for 60 seconds
- Isolation Capacitance: 1200 pF approx.
- Isolation Resistance: >1000 MΩ at 500V
- Switching Frequency: ~400 kHz
- Operating Temperature Range: -40°C to +85°C
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Case Material: Metal with non-conductive baseplate
- Soldering Temperature: Max 260°C at 1.5mm from case for 10 sec
- Safety Standards: UL/cUL 60950-1, IEC/EN 60950-1
- Certifications: UL, cUL, EN 60950-1
- Compliance: Reach, RoHS
- Remote On/Off control, efficiency, EMC compliance, and transient response optimized for demanding industrial environments
Buy the Buy TracoPower THD 10 Series Part Number THD101212N Online
Securely purchase the TracoPower THD 10 series DC/DC converter online today to ensure your system’s reliable power supply. With a compact design, high efficiency up to 89%, and internal EMI filter, these converters are ideal for industrial control, instrumentation, and communication equipment. Supporting input voltages of 12VDC, 24VDC, and 48VDC, with multiple output options and robust isolation of 1500VDC, they deliver excellent performance across temperatures from -40°C to +85°C. Trust TracoPower’s quality for demanding applications requiring dependable and efficient power conversion with safety certifications included.
Order your TracoPower THD 10 Series THD101212N today and enhance your industrial and communication projects with reliable high-performance DC/DC converters.
Frequently Asked Questions
Where can I buy TRACO POWER THD101212N?
You can click on the BUY or RFQ button to purchase THD101212N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD101212N?
You can download the THD101212N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD101212N?
TRACO POWER
