TRACO POWER TEN87212WI DC/DC Converter Module
The TEN 8WI series comprises high-performance 8-watt DC/DC converter modules with ultra-wide 4:1 input voltage ranges of 9-36 V, 18-75 V, and 43-160 VDC, designed for demanding applications such as railway, transportation, telecom, and industrial systems. Features include EN 50155 approval, high efficiency up to 88%, remote On/Off control, over-voltage and under-voltage protection, and a shielded metal case. Operating temperatures span -40°C to +85°C, with excellent EMC compliance, vibration and thermal shock resistance, making them ideal for reliable, precise power conversion in harsh environments.
TRACO POWER TEN87212WI DC/DC Converter Module Specifications:
- Input Voltage Range: 9-36 V, 18-75 V, 43-160 VDC
- Output Voltages: 3.3 V, 5 V, 12 V, 15 V, 18 V, 24 V, 48 V, 110 VDC nominal
- Maximum Output Currents: 2/400 mA, 1,600 mA, 533 mA, 800 mA, 666 mA, 267 mA, 333 mA
- Efficiency: Up to 88%
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 1500 VDC
- Inrush Current: 13-40 mA (no load) / 10-210 mA (full load)
- Surge Voltage: 50-170 V max.
- Ripple & Noise: 50-75 mVp-p
- Switching Frequency: ~300 kHz
- Protection: Overvoltage, undervoltage lockout, short circuit, overcurrent
- Dimensions: Copper casing, 18 g weight, soldering max 265°C, anti-vibration compliance
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, EN 50155, RoHS, Reach
- Remote On/Off: 0-12 VDC or open, off: 0-1.2 VDC
- Isolation Resistance: >1000 MΩ
- Switching Type: PWM
Buy the Buy TracoPower TEN 8WI Series Power Module Part Number TEN87212WI Online
Experience the high efficiency and reliable power conversion of the TracoPower TEN 8WI series. These 8-watt DC/DC converters feature ultra-wide input voltages, EN 50155 approval, remote On/Off, and multiple protections. Designed for demanding environments, they operate from -40°C to +85°C and provide excellent EMC performance. Their rugged shielded metal case ensures durability, making them ideal for railway, telecom, industrial control, and measurement applications. Purchase online today for a dependable, space-saving power solution with extended warranty and compliance.
Get TracoPower TEN87212WI today—compact, reliable power supply solution for industrial and transportation systems.
Frequently Asked Questions
Where can I buy TRACO POWER TEN87212WI?
You can click on the BUY or RFQ button to purchase TEN87212WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN87212WI?
You can download the TEN87212WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN87212WI?
TRACO POWER
