TRACO POWER TEN82411 DC/DC Converter
The TEN 8 series by Traco Power is a family of high-performance, 8-watt DC/DC converters designed for compact applications demanding reliable power. Encased in a shielded metal housing with an insulated baseplate, these modules feature a wide 2:1 input voltage range, high efficiency, and extended operational temperature from -40°C to +85°C. They include an EMI filter meeting EN 55022, class A standards, remote On/Off control, and short-circuit protection. Suitable for battery-powered, instrumentation, communication, and industrial electronics, these converters ensure stable, isolated voltages in limited space environments, with a 3-year warranty.
TRACO POWER TEN82411 DC/DC Converter Specifications:
- Input voltage range: 12 V, 24 V, 48 V, and other models with surge voltages up to 100 V max.
- Output voltages: 3.3 V, 5 V, 9-18 V, 12 V, 15 V, with currents up to 2000 mA.
- Input current (no load): 10-15 mA; full load: 180-720 mA depending on voltage model.
- Isolation voltage: 1500 VDC (input/output), capacitance: 300 pF, resistance: >1000 MΩ.
- Efficiency: High efficiency suitable for battery-operated and space-limited applications.
- Operating temperature: -40°C to +85°C with derating above +70°C at 3.3%/K.
- Ripple and noise: 50 mV pk-pk; startup time: 700 ms; transient response: 200 ps.
- Protection: Short circuit, over load (150%), and automatic recovery; remote on/off (5–12 VDC).
- Physical: Copper case, epoxy potting, weight 17 g, with UL and RoHS compliance.
- Regulation: Input variation 0.2%, load variation 1-5%, temperature coefficient 0.02%/K.
Buy the Traco Power Series TEN 8 DC/DC Converter: TEN 8-1211
Purchase the Traco Power TEN 8-1211 5V DC/DC converter online today and ensure a stable, reliable power supply for your industrial, communication, or instrumentation equipment. Featuring high efficiency, wide input voltage range, and built-in EMI filtering, this compact converter offers exceptional performance in limited space environments. Its remote On/Off control, short-circuit protection, and wide operating temperature range from -40°C to +85°C make it ideal for demanding applications. Order now and enjoy fast delivery combined with robust, long-lasting power solutions for your critical systems.
Buy Traco Power TEN 8-1211 high-efficiency 5V DC/DC converter now and experience unmatched reliability and performance for your electronics projects.
