TRACO POWER TME0509S DC/DC Converter
The TME series is a set of ultra-compact, high-efficiency 1 Watt isolated DC/DC converters in a SIP package, requiring only 0.7 cm2 of board space. Designed for reliable power supply with industry-standard pinout, these converters feature up to 80% efficiency, operating temperature from -40°C to +85°C, and 1000 VDC isolation. They undergo 100% burn-in, are lead-free, ROHS compliant, and provide a cost-effective solution for generating isolated voltages in various industrial and electronic applications, ensuring high reliability and long service life.
TRACO POWER TME0509S DC/DC Converter Specifications:
- Input Voltage Range: 3.3 VDC, 5 VDC, 12 VDC, 24 VDC
- Output Voltage Options: 3.3 V, 5 V, 9 V, 12 V, 15 V
- Max Output Current: 80 mA to 260 mA depending on model
- Efficiency: Up to 80%
- Isolation Voltage: 1000 VDC
- Operating Temperature: -40°C to +85°C
- Burn-in Testing: 100%
- Efficiency Range: 70% to 80%
- Ripple & Noise: 150 mV pk-pk
- Switching Frequency: 90 kHz
- Package Material: Non-conductive black plastic, UL 94V-0 rated
- Dimensions: Designed to occupy 0.7 cm² of PCB space
- Lead-Free and RoHS Compliant
- Humidity Tolerance: Up to 95% RH
- Soldering Temperature: Max 265°C for 10 seconds
Buy the Buy TracoPower Power TME Series 1 Watt Part Number TME0509S Online
Order the TracoPower TME Series 1 Watt DC/DC converter online today and benefit from a highly reliable, efficient isolated power solution. With industry-standard pinout, up to 80% efficiency, wide operating temperature range, and 1000 VDC isolation, this compact device is perfect for demanding industrial and electronic applications. Its UL 94V-0 rated casing, flexible input voltages, and strict quality testing ensure long-term dependable operation. Purchase now for fast availability and superior power isolation performance for your project needs.
Buy TracoPower TME Series 1 Watt compact, high-efficiency DC/DC converter now and experience reliable performance suitable for industrial power applications.
Frequently Asked Questions
Where can I buy TRACO POWER TME0509S?
You can click on the BUY or RFQ button to purchase TME0509S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME0509S?
You can download the TME0509S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME0509S?
TRACO POWER
