TRACO POWER TMDC602415 Industrial Power Converter
The TracoPower TMDC 60-2415 is a 60W high-performance single-output DC-DC converter module housed in a fully encapsulated, low-profile plastic case. Available in chassis mount with screw terminal or PCB versions, it features a 4:1 input voltage range from 9VDC to 36VDC and provides a 24VDC output with a maximum current of 2500mA. The converter boasts a high efficiency of 91% at a switching frequency of 285kHz and does not require a minimum load. It includes features such as remote on/off control, automatic recovery from short circuit conditions, overload, and short circuit protection. The module offers excellent electrical isolation with 2500VDC I/O isolation voltage, resistance greater than 1000MΩ, and capacitance up to 3000pF. It is designed to operate in temperatures from -40°C to 85°C and is compliant with UL/cUL 60950-1, IEC 60950-1:2005, and CSA C22.2 No. 60950-1-07 standards, with additional immunity standards EN 55024 and EN 61000-4-2. Optional DIN rail mounting is available. Suitable for power management and industrial applications.
TRACO POWER TMDC602415 Industrial Power Converter Specifications:
- Input Voltage Range: 9VDC to 36VDC (4:1 ratio)
- Output Voltage: 24VDC, Max Current: 2500mA
- Efficiency: 91% at typical load
- Switching Frequency: 285kHz
- Isolation Voltage: 2500VDC I/O isolation
- Isolation Resistance: >1000MΩ
- Input Current at No Load: 60mA (48V model)
- Start-up Time: 50 ms max.
- Operating Temperature Range: -40°C to 85°C
- Storage Temperature: -40°C to +125°C
- Dimensions: Compact, encased in low-profile plastic
- Protection: Overload, short circuit, and overvoltage
- Standards: UL/cUL 60950-1, IEC 60950-1, CSA
- Immunity: EN 55024, EN 61000-4-2, 3, 4, 5, 6, 8
- Certifications: UL, cUL, IEC, CSA compliant
- Maximum Capacitance: 3000pF
- Operating in altitude up to 2000m natural convection
Buy the TracoPower TMDC602415 – Reliable Power Conversion for Industrial Applications
Purchase the TracoPower TMDC 60-2415 online today—engineered for high-performance industrial applications. With a compact design, 91% efficiency, and 2500VDC electrical isolation, this 60-watt converter offers reliable power in a wide temperature range from -40°C to 85°C. Features include remote on/off, overcurrent, and short circuit protection for enhanced safety and durability. Its universal input range supports 9V to 36V, making it ideal for robust power management in automation, controls, and industrial equipment. Order today for fast delivery and dependable performance!
Get TracoPower TMDC602415 today—built for precision, high efficiency, and rugged industrial environments.
