TRACO POWER TEN62412N DC-DC Converter
The TEN 6-2412N from TracoPower is a high-performance, single-output 6W DC-DC converter housed in a 24-pin DIP package. Designed for an optimal balance of cost and performance, it features overload protection, internal filtering in accordance with EN55022 Class A standards, no minimum load requirement, and high efficiency. This converter provides a wide input voltage range from 18VDC to 36VDC, with a typical output of 12VDC and a maximum load current of 500mA. It offers an efficiency of approximately 84%, reinforced by continuous, automatic recovery short circuit protection. The device has a 1500VDC I/O isolation voltage, a voltage regulation accuracy of ±2%, and operates at a switching frequency of 330kHz. Its compact dimensions measure 20.3mm x 10.2mm x 31.8mm. Certified under UL/cUL 60950-1 and IEC/EN 60950-1 standards, it is suitable for distributed power architectures, workstations, computer equipment, and communications infrastructure. The case is made from UL 94V-0 rated non-conductive plastic and epoxy potting, with a start-up voltage of 18VDC and surge voltage capability up to 50V for 1 second. Operating temperature ranges from -40°C to +85°C.
TRACO POWER TEN62412N DC-DC Converter Specifications:
- Input Voltage Range: 18VDC to 36VDC
- Output Voltage: 12VDC
- Output Current Max: 500mA
- Efficiency: 84%
- Isolation Voltage: 1500 VDC
- Voltage Regulation Accuracy: ±2%
- Switching Frequency: 330kHz
- Operating Temperature Range: -40°C to +85°C
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Case Material: UL 94V-0 rated plastic with epoxy potting
- Start-up Voltage: 18VDC
- Surge Voltage: Up to 50V for 1 second
- Protection: Overload and short circuit, automatic recovery
- Input Current at No Load: 300mA (24V models)
- Input Current at Full Load: 610mA (24V models)
- Compliance: UL/cUL 60950-1, IEC/EN 60950-1, EN55022 Class A
Buy the Buy TracoPower DC-DC Converter Part Number TEN62412N Online
Order the TracoPower TEN62412N DC-DC converter online today to enjoy a compact, high-efficiency power solution with no minimum load requirement, ideal for industrial, communication, and medical equipment. Featuring load regulation, overload protection, and UL/EN safety standards, this 6W converter provides a wide input voltage range from 18VDC to 36VDC, with 12VDC output at 500mA. Its robust design includes 1500VDC isolation, automatic short circuit recovery, and compliance with EMI standards. Perfect for designing reliable power supplies in space-constrained environments.
Buy TracoPower TEN62412N now and experience reliable power conversion with high efficiency and robust isolation for industrial and communication applications.
Frequently Asked Questions
Where can I buy TRACO POWER TEN62412N?
You can click on the BUY or RFQ button to purchase TEN62412N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN62412N?
You can download the TEN62412N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN62412N?
TRACO POWER
