TRACO POWER TEN84823WI DC/DC Converter
The TEN 8WI series is a high-performance 8 Watt DC/DC converter family designed with an ultra-wide 4:1 input voltage range up to 160 VDC, suitable for demanding transportation and industrial applications. Features include EN 50155 railway approval, high efficiency up to 88%, remote On/Off, under-voltage lockout, short circuit protection, and a shielded metal case with insulated base plate. Operable from -40°C to +85°C, these converters are ideal for telecom, wireless networks, control systems, and measurement equipment, offering reliable performance in harsh environments.
TRACO POWER TEN84823WI DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC, 18-75 VDC, 43-160 VDC with 4:1 ratio
- Output Voltages: 3.3 V, 5 V, 12 V, 15 V, 24 V, 48 V, 110 VDC nominal
- Output Current: 800 mA to 2,400 mA depending on model
- Efficiency: up to 88%
- Operating Temp: -40°C to +85°C
- Isolation Voltage: 1500 VDC input/output
- Ripple and Noise: 50-75 mVp-p
- Dimensions: Compact DIP-24 package, weight approx. 18 g
- Protection: Short circuit, over voltage, undervoltage lockout, surge voltage up to 170 V
- Switching Frequency: 300 kHz
- Certifications: UL, cUL, IEC, EN 50155, RoHS, Reach
- Environmental: Vibration, thermal shock, EN 61373 compliant
- Soldering Temperature: Max 265°C for 10 sec
- MTBF: 1 million hours at +25°C
Buy the Traco Power Series TEN 8WI DC/DC Converter: TEN84823WI
Enhance your system's power stability with the Traco Power TEN 8WI series DC/DC converter. Featuring ultra-wide input voltage range up to 160 VDC, high efficiency, EN 50155 railway approval, and comprehensive protections, this 8-watt converter is perfect for rail, telecom, wireless networks, and industrial control systems. Its rugged design withstands harsh environments from -40°C to +85°C, ensuring reliable operation. Easy to install, with minimal maintenance, this converter offers superior performance, safety, and compliance, making it an ideal choice for critical applications requiring stable power conversion.
Buy Traco Power TEN84823WI now and experience unmatched reliability and performance in demanding industrial and transportation environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEN84823WI?
You can click on the BUY or RFQ button to purchase TEN84823WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN84823WI?
You can download the TEN84823WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN84823WI?
TRACO POWER
