TRACO POWER TVN30915 DC/DC Converter
The TVN 3 Series is a compact 3 Watt DC/DC converter offering ultra low ripple and noise of 10 mVp-p, fully regulated outputs, and a wide input voltage range from 4.5V to 75V. Designed for space-limited applications, it features 1,600 VDC isolation, operates reliably up to 75°C without derating, and includes short circuit protection and no minimum load requirement. Its robust design suits industrial and embedded systems, ensuring stability, efficiency, and safety in harsh environments with comprehensive EMC compliance.
TRACO POWER TVN30915 DC/DC Converter Specifications:
- Input Voltage Range: 4.5-75 VDC, extended models 4.5-13.2 VDC
- Output Power: 3 Watt
- Output Voltage Options: 3.3V, 5V, 9V, 12V, 15V, 24V, 42V, 48V, 36V, 75V
- Maximum Output Current: 700 mA
- Efficiency: Up to 85%
- Isolation Voltage: 1,600 VDC
- Operating Temperature Range: -40°C to +90°C, derating above 75°C
- Ripple and Noise: 10 mVp-p typical, without external components
- Transient Response: 500 µs
- Start-up Voltage: 4.5V to 9V depending on model
- Undervoltage Shutdown: Typical 3.5V to 33V
- Surge Voltage (1 s): Up to 100 V max
- Input Current (No Load): 9 V in 55 mA
- Isolation Capacitance: 1,500 pF max
- Dimensions: Compact SIP-8 package; length approximately 15 mm
- Certification: UL/CSA/EN 60950-1, RoHS Compliant
Buy the Traco Power Series TVN 3 DC/DC Converter: TVN30915
Enhance your electronic projects with the Traco Power TVN 3 series DC/DC converter. This compact, low ripple module offers wide input voltage range, high efficiency, and robust isolation suitable for space-constrained industrial applications. Reliable operation up to 75°C without derating ensures durability in harsh environments. Its fully regulated outputs and short circuit protection provide stability and safety, making it an ideal choice for demanding automation, control, and embedded systems. Purchase online today for fast delivery and trusted quality.
Buy Traco Power TVN 3 series 3 Watt DC/DC converter now and experience unmatched reliability and performance for industrial and embedded systems.
Frequently Asked Questions
Where can I buy TRACO POWER TVN30915?
You can click on the BUY or RFQ button to purchase TVN30915 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TVN30915?
You can download the TVN30915 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TVN30915?
TRACO POWER
