TRACO POWER TMA1205D Miniature DC/DC Converter
The TMA series are compact, single-in-line package DC/DC converters designed for space-constrained applications. They provide up to 1 watt power output with models featuring single or dual outputs, Industry standard pinout, and high efficiency up to 81%. Operating from -40°C to +85°C, these unregulated devices offer 1000 VDC isolation, ROHS compliance, and a 3-year warranty, making them ideal for board-level power distribution in industrial automation, control systems, and electronic equipment where high performance and reliability are crucial.
TRACO POWER TMA1205D Miniature DC/DC Converter Specifications:
- Input Voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC models
- Output Voltage: 5 VDC, 12 VDC, 15 VDC models
- Output Current Max: 200 mA for 5 V, 84 mA for 12 V, 67 mA for 15 V models
- Efficiency: Up to 81%
- Operating Temperature Range: -40°C to +85°C
- Isolation Voltage: 1000 VDC
- Mounting: Single-in-line (SIP), SMD technology
- Dimensions: Compact package with specific dimensions for different models
- Temperature Coefficient: +0.01 %/K typical
- Ripple & Noise: 50 mVp-p (20 MHz bandwidth)
- Certifications: RoHS compliant, UL94V-0 casing material
- Soldering Temp: Max 260°C / 10 sec
- Reliability MTBF: Over 2,000,000 hours at +25°C
- Weight: 2.2 g to 2.6 g depending on model
Buy the TRACO Power TMA1205D – Reliable 1W DC/DC Converter for Industrial Applications
Explore the TRACO Power TMA1205D miniature 1-watt DC/DC converter online today. Featuring high efficiency, excellent isolation of 1000 VDC, and operation across -40°C to +85°C, this compact power solution is perfect for industrial automation, control systems, and electronic device applications. Its SIP package saves space on your PCB while providing reliable unregulated power with industry-standard pin configuration. Trust in proven quality, RoHS compliance, and a 3-year warranty for your critical power requirements.
Buy TRACO Power TMA1205D now and experience unmatched reliability and performance in your power management systems.
Frequently Asked Questions
Where can I buy TRACO POWER TMA1205D?
You can click on the BUY or RFQ button to purchase TMA1205D from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMA1205D?
You can download the TMA1205D datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMA1205D?
TRACO POWER
