TRACO POWER TEM31211N dc-dc converter
The TEM 3N series is a cost-effective, isolated DC/DC converter range in DIP-24 packages, offering tight regulation, low noise, and an operating temperature range of -40°C to +85°C. Designed for industrial and consumer electronics, these converters provide fully regulated outputs, short circuit protection, and meet EN 55022, class A standards. Models feature input voltages from 5V to 24V, with output currents up to 600mA, and efficiencies reaching 82%. They are optimized for reliable performance across various applications requiring compact, efficient power solutions.
TRACO POWER TEM31211N dc-dc converter Specifications:
- Input Voltage Range: 5 VDC to 24 VDC
- Output Voltage: 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Current Max: 600 mA
- Efficiency: Up to 82%
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 1500 VDC
- Ripple & Noise: 30 mVp-p typ.
- Switching Frequency: 300 kHz typ.
- Temperature Coefficient: +0.02 %/K
- Dimensions: DIP-24 package, weight approximately 12.4 g
- Certification: UL, IEC, EN standards
- Protection: Short circuit, automatic recovery
- Input Filter: Meets EN 55022, class A
- Soldering Temperature Max: 260°C / 10 sec.
Buy the Traco Power Series TEM 3N DC/DC Converter: TEM31211N
Experience reliable power conversion with the Traco Power TEM31211N DC/DC converter. This cost-effective, regulated, and low-noise module provides up to 600mA output current, operates within -40°C to +85°C temperatures, and meets all safety standards. Its compact DIP-24 design makes it ideal for industrial and consumer electronics, ensuring efficient, stable performance. Easy to integrate, with robust short circuit protection and high isolation voltage, it’s the perfect choice for demanding power supply applications requiring consistent, high-quality regulation.
Get Traco Power TEM31211N today—built for precise regulation, low noise, and reliable industrial power conversion.
Frequently Asked Questions
Where can I buy TRACO POWER TEM31211N?
You can click on the BUY or RFQ button to purchase TEM31211N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEM31211N?
You can download the TEM31211N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEM31211N?
TRACO POWER
