TRACO POWER TEN82422 DC-DC Converter
The TEN 8-2422 is a two-output, board-mounted isolated DC-DC converter offering tightly regulated output voltages with a wide 2:1 input voltage range. This high-performance 8W converter features an industry-standard footprint, short-circuit protection, and an efficient design with up to 86% efficiency. It includes an input filter compliant with EN 55022, class A standards, and offers remote on/off control. The shielded metal casing with insulated baseplate ensures durability and electrical isolation. Suitable for applications requiring isolated, precisely regulated voltages in space-constrained PCB environments, the converter operates reliably across a temperature range from -40°C to +85°C.
TRACO POWER TEN82422 DC-DC Converter Specifications:
- Input Voltage Range: 18-36 VDC
- Output Voltage: 12 VDC
- Output Current Max: 665 mA
- Efficiency: Up to 86%
- Isolation Voltage: 1500 VDC
- Isolation Resistance: >1000 MΩ
- Isolation Capacitance: 300 pF
- Operating Temperature: -40°C to +85°C
- Casing Material: Copper, nickel plated
- Baseplate Material: Non-conductive plastic
- Potting Material: Epoxy UL PAV-0
- Dimensions: 15.24 mm x 15.24 mm x 8.0 mm
- Weight: 17 g
- Soldering Temperature Max: 265°C / 10 sec.
Buy the Traco Power TEN 8-2422 Reliable Isolated DC-DC Converter for Industrial Applications
Purchase the Traco Power TEN 8-2422 online today and ensure your equipment achieves optimal power isolation and regulation. This compact 8W DC-DC converter with wide input range, high efficiency up to 86%, and remote on/off control is ideal for demanding industrial, communication, and instrumentation applications where space is limited. With proven reliability, high-quality materials, and safety certifications, it provides a robust power solution that guarantees stability and safety across operating temperatures from -40°C to +85°C. Get yours now for seamless integration and long-term performance.
Order your Traco Power SeriesTEN 8-2422 high-efficiency isolated DC-DC converter today and ensure your industrial projects benefit from dependable, space-efficient power conversion.
Frequently Asked Questions
Where can I buy TRACO POWER TEN82422?
You can click on the BUY or RFQ button to purchase TEN82422 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN82422?
You can download the TEN82422 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN82422?
TRACO POWER
