TRACO POWER TEXC11 Industrial Power Supply
The TEXC11 is a rugged industrial power supply designed for harsh outdoor environments, featuring a die-cast aluminium housing resistant to water, dust, ice, and oil. It has an IP67 and NEMA 4X rating, operates from -40°C to +85°C, and includes waterproof connectors. Certified for ATEX and IECEx zones, it provides reliable power with low ripple and noise, a DC-OK indicator, and adjustable outputs suitable for demanding industrial automation applications.
TRACO POWER TEXC11 Industrial Power Supply Specifications:
- Power Output: 120 W
- Output Voltage: 24 VDC (adjustable 24-28 VDC)
- Output Current: 5.0A
- Input Voltage Range: 85-264 VAC, 47-63 Hz
- Input Current: 1.0 A at 230 VAC, 2.0 A at 115 VAC
- Operating Temperature: -40°C to +85°C
- Efficiency: 87%
- Protection: Electronic short circuit, overvoltage <40V, hold-up time >20 ms
- Physical: Die-cast aluminium enclosure, IP67, NEMA 4X rated
- Dimensions: 93 mm x 83 mm x 56 mm
- Weight: 1000 g
- Certifications: UL, CB, IECEx, ATEX, Reach, RoHS
- Vibration: IEC 60068-2-6; Shock: IEC 60068-2-27
- Safety Standards: IEC/EN 60950-1, IEC/EN 60079-15, UL 508
- EMC: EN 61000-6-3, EN 61000-6-2
Buy the Buy Traco Power TEX 120 Series Part Number TEXC11 Online
Purchase the Traco Power TEXC11 industrial power supply online to ensure your automation systems operate reliably in extreme outdoor conditions. With its rugged aluminium housing, waterproof IP67 protection, and ATEX certification, the TEXC11 is ideal for hazardous environments. This power supply offers adjustable output voltages, low ripple, and noise, guaranteeing stable power for sensitive equipment. Its robust construction ensures durability against dust, water, ice, and oil, making it an excellent choice for demanding industrial applications requiring dependable power supply solutions.
Order your Traco Power TEXC11 rugged industrial power supply today and enjoy reliable, outdoor-rated power suitable for critical automation environments.
Frequently Asked Questions
Where can I buy TRACO POWER TEXC11?
You can click on the BUY or RFQ button to purchase TEXC11 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEXC11?
You can download the TEXC11 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEXC11?
TRACO POWER
