TRACO POWER TMR0521 DC/DC Converter Module
The TMR 0521 is a compact 2W isolated DC/DC converter module designed for space-critical applications like communication equipment, instrumentation, and industrial electronics. It features a wide 2:1 input voltage range of 5VDC to 10VDC, with regulated output at +5VDC and a maximum current of 200mA. The module offers high efficiency, full SMD design, and an operating temperature from -40°C to +85°C. Additional features include remote On/Off control, continuous short-circuit protection, and UL60950-1 compliance, making it a reliable solution for power conversion needs in demanding environments.
TRACO POWER TMR0521 DC/DC Converter Module Specifications:
- Input Voltage Range: 5VDC to 10VDC
- Output Voltage: +5 VDC
- Maximum Output Current: 200 mA
- Efficiency: 64%
- Working Temperature: -40°C to +85°C
- Isolation Voltage: 1000 VDC
- Operating Humidity: 95% RH
- Switching Frequency: 100 to 650 kHz
- Dimensions: 21.8 mm x 11.14 mm x 8.0 mm
- Weight: 48 g
- Protection: Short-circuit, automatic recovery
- Construction: Epoxy potting, non-conductive plastic casing
- Safety: UL60950-1, RoHS, Reach compliant
Buy the TracoPower TMR0521 – Reliable DC-DC Converter for Industrial Applications
Purchase the TracoPower TMR0521 DC/DC converter online today to benefit from its compact size, high efficiency, and reliable power output. Designed for space-constrained industrial applications, this 2W module features a wide input voltage range from 5V to 10V, regulated 5V output, and robust protection features including short-circuit protection and UL compliance. Its high performance and small footprint make it ideal for communication equipment, instrumentation, and industrial electronics. Click now to secure fast delivery and upgrade your power solutions with proven quality.
Order your TracoPower TMR0521 series compact 2W DC/DC converter today and ensure dependable power conversion for your industrial projects.
