TRACO POWER THL202412WI DC/DC Power Converter
The THL 20W series is a compact, high-efficiency DC/DC power converter module designed for space-constrained applications. With an ultra-wide 4:1 input voltage range and up to 90% efficiency, it provides reliable power in industrial, communication, and mobile equipment. Its shielded metallic case with isolated baseplate supports operating temperatures up to +75°C or +85°C with a heatsink. Suitable for distributed power architectures, it features adjustable output voltage, remote On/Off control, 1500 VDC isolation, and a 3-year warranty, ensuring durability and safety compliance.
TRACO POWER THL202412WI DC/DC Power Converter Specifications:
- Dimensions: 1.0 x 1.0 x 0.4 inches (25.4 x 25.4 x 10.16 mm)
- Case Material: Aluminum alloy
- Input Voltage Range: 3.3 VDC to 75 VDC with models available for 12 VDC, 24 VDC, and 48 VDC inputs
- Output Voltage: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 24 VDC
- Max Output Current: 835 mA to 4500 mA depending on model
- Efficiency: Up to 90%
- Operating Temperature: -40°C to +75°C, up to +85°C with heatsink
- Isolation Voltage: 1500 VDC
- Ripple & Noise: 75 to 150 mVp-p depending on model
- Switching Frequency: 330 kHz
- Weight: 15 g
- Soldering Temperature: 260°C for 10 seconds maximum
- Certifications: UL, cUL, IEC/EN 60950-1, RoHS
Buy the TracoPower Series THLDC20W Power Converter: THL202412WI
Order the TracoPower THL202412WI DC/DC power converter online today to enjoy high efficiency, wide input range, and robust isolation. Designed for industrial, communication, and mobile applications, this 20W module offers reliable performance, adjustable output voltage, and compact design. With a universal input voltage, excellent thermal management, and compliance with safety standards, it ensures seamless integration into critical systems. Purchase now to benefit from fast delivery, competitive pricing, and trusted quality assurance for your electronic projects.
Buy TracoPower THL202412WI now and experience unmatched reliability and industrial-grade performance in compact form factors.
Frequently Asked Questions
Where can I buy TRACO POWER THL202412WI?
You can click on the BUY or RFQ button to purchase THL202412WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THL202412WI?
You can download the THL202412WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THL202412WI?
TRACO POWER
