TRACO POWER THM61211 Medical DC/DC Converter
The THM 6 Series is a range of medical 6 Watt DC/DC converters designed with DIP-24 plastic cases, offering high efficiency up to 89% and low leakage current below 2 yA. They provide reinforced insulation with 5000 VACrms isolation, certified for IEC/EN/ES 60601-1 third edition for 2 MOPP safety standard, and operate reliably within temperatures from -40°C to +90°C. These converters are suitable for medical, transportation, and control applications, complying with EMC standards, offering adjustable output voltages, and ensuring safety and reliability in demanding environments.
TRACO POWER THM61211 Medical DC/DC Converter Specifications:
- Input voltage range: 4.5 - 36 VDC
- Output voltage options: 3.3 V, 5 V, 12 V, 15 V, 24 V, 36 V, 48 V
- Output current: up to 1800 mA depending on model
- Efficiency: up to 89%
- Isolation voltage: 5000 VACrms
- Operating temperature: -40°C to +90°C (full load)
- Leakage current: less than 2 yA
- Protection: Over load at 150%, short circuit, over voltage
- Start-up voltage: 4.5 V to 36 V
- EMC compliance: IEC 60601-1-2, EN55032 class A
- Dimensions: DIP-24 plastic casing
- Certification: IEC/EN/ES 60601-1, ISO 13485, UL
- Application: Medical equipment, transportation, measurement, IGBT drivers
- Soldering temperature: max 265°C for 10 seconds
- Altitude: operational up to 5000 meters
Buy the Traco Power THM 6-0510 – Reliable Medical Power Supply for Industrial Applications
Purchase your Traco Power Series THM 6-0510 medical-grade 6 Watt DC/DC converter online today. This compact, high-efficiency power supply features reinforced insulation, low leakage current, and extensive safety certifications. Perfect for medical equipment, transportation, and industrial controllers, it guarantees reliable operation across a wide temperature range from -40°C to +90°C. With IEC 60601-1 compliance and a 5000 VACrms isolation rating, it ensures user safety. Easy to integrate into demanding environments, it’s your dependable power solution for critical applications.
Order your Traco Power Series THM 6-0510 medical-grade DC/DC converter today and ensure safe, efficient power supply for demanding medical and industrial projects.
Frequently Asked Questions
Where can I buy TRACO POWER THM61211?
You can click on the BUY or RFQ button to purchase THM61211 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM61211?
You can download the THM61211 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM61211?
TRACO POWER
