TRACO POWER TEN82421WI High-Performance DC/DC Converter
The TEN 8WI series comprises high-performance 8 Watt DC/DC converter modules with ultra wide 4:1 input voltage ranges from 9-36 VDC, 18-75 VDC, and 43-160 VDC, ideal for demanding transportation, railway, and industrial applications. Features include remote On/Off, over-voltage, undervoltage lockout, short circuit protection, high efficiency up to 88%, and robust construction with shielded metal case. Certified for EN 50155 railway standards, operating from -40°C to +85°C, and compliant with RoHS, these modules deliver reliable power conversion for telecom, control systems, and measurement equipment.
TRACO POWER TEN82421WI High-Performance DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC, 18-75 VDC, 43-160 VDC
- Output Voltage Options: 3.3 V, 5 V, 12 V, 15 V, 24 V, 48 V, 110 V, 12 V, 15 V
- Output Current Max: From 266 mA to 2,400 mA depending on model
- Efficiency: Up to 88%
- Operating Temperature Range: -40°C to +85°C
- Isolation Voltage (Input/Output): 1500 VDC
- Ripple & Noise (20 MHz BW): 50-75 mVp-p
- Surge Voltage: Up to 170 V max
- Power Derating: 3%/K above 70°C
- Switching Frequency: 300 kHz typ.
- Case Material: Copper, nickel plated; epoxy potting
- Dimensions: Compact DIP-24 package with dimensions in mm
- Certifications: EN 50155, UL/cUL 60950-1, RoHS, Reach
- Lifetime: MTBF approximately 2.8 million hours
- Protection: Over Voltage, Over Load (150%), Short Circuit, Undervoltage Lockout
- Remote On/Off Control: Compatible with 0-12 VDC or open circuit
- Soldering Temperature: Max 265°C for 10 sec.
Buy the Traco Power Series TEN 8WI DC/DC Converter: TEN82421WI
Experience the durability and efficiency of the Traco Power TEN82421WI, a compact 8 Watt DC/DC converter designed for demanding environments like transportation and industrial systems. With ultra wide input voltage range from 9 VDC to 160 VDC, high efficiency up to 88%, and robust shielded metal case, this module provides reliable power conversion. Featuring EN 50155 certification for railway applications, remote On/Off, over-voltage, and short circuit protection, the TEN82421WI is the ideal choice for engineers seeking dependable industrial power solutions. Order online today for fast delivery and exceptional performance.
Get Traco Power TEN82421WI today—built for precision, efficiency, and reliable industrial power conversion.
Frequently Asked Questions
Where can I buy TRACO POWER TEN82421WI?
You can click on the BUY or RFQ button to purchase TEN82421WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN82421WI?
You can download the TEN82421WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN82421WI?
TRACO POWER
