TRACO POWER THL104812 industrial DC/DC converter
The THL 10 series from TracoPower consists of 10W single and dual output DC/DC converters housed in a compact 1" x 1" metal case with isolated baseplate. These versatile, industrial-standard converters feature a wide 2:1 input voltage range, with models available for 12V, 24V, or 48V DC inputs. They provide various output voltages including 3.3V, 5.1V, 12V, 15V, and dual ±5V, ±12V, or ±15V configurations, with maximum output currents up to 2A. Designed for ease of use, they incorporate input filters that meet EN 55022 Class A standards without external components, and feature protections against short circuits and overvoltage. Operating efficiently with up to 89% efficiency, they maintain operational temperature ranges from -40°C to +80°C, up to +85°C with a heatsink. Typical applications include instrumentation, distributed power architectures in telecommunications, and industrial electronics. Safety-certified to UL/cUL 60950-1 and IEC/EN 60950-1 standards, they come with a 3-year warranty.
TRACO POWER THL104812 industrial DC/DC converter Specifications:
- Input Voltage Range: 12V, 24V, 48V DC models with wide 2:1 ratio
- Output Voltages: 3.3V, 5.1V, 12V, 15V, ±5V, ±12V, ±15V
- Output Currents: Up to 2A depending on model
- Efficiency: Up to 89%
- Operating Temperature Range: -40°C to +80°C, up to +85°C with heatsink
- Isolation Voltage: 1500 VDC
- Enclosure: Metal case with isolated baseplate
- Protection: Short circuit and overvoltage
- Input Filter Compliance: EN 55022 Class A without external components
- Soldering Temp: Max +260°C for 10 sec
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1
- MTBF: 2,596,000 hours according to MIL-HDBK-217F
Buy the Buy TracoPower DC/DC Converter Part Number THL104812 Online
Discover the TracoPower THL 10 series, a reliable 10W industrial DC/DC converter designed for demanding applications. Featuring a compact 1" x 1" metal case, these versatile converters offer wide input voltage ranges of 12V, 24V, or 48V, and deliver high efficiency up to 89%. They include multiple output options such as 3.3V, 5.1V, 12V, and 15V, with built-in protections against short circuits and overvoltage. Operating reliably from -40°C to +85°C with heatsinks, these converters are ideal for instrumentation, telecom, and industrial electronics. Certified to UL/cUL 60950-1 and IEC/EN 60950-1 standards, with a 3-year warranty, they ensure durable, safe power conversion for your projects. Buy online now for fast delivery and trusted quality.
Order your TracoPower Series THL 10-4812 12V 830mA DC/DC Converter today and enhance your industrial power solutions with reliable and efficient performance.
