TRACO POWER THL102412 DC/DC Converter
The THL 10 series from TracoPower consists of 10W single and dual output DC/DC converters. These compact modules are housed in a 1" x 1" case and are pin-compatible with larger models. They feature a wide 2:1 input voltage range, input filter meeting EN 55022 class A, and protections against short circuits and overvoltage. Operating from -40°C to +80°C (up to +85°C with heat sink), they suit instrumentation, communication, and industrial electronics. They deliver high efficiency up to 89%, provide 1500VDC isolation, and meet UL/cUL 60950-1 and IEC/EN 60950-1 safety standards, supported by a 3-year warranty.
TRACO POWER THL102412 DC/DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: 12V, 24V, 48V DC
- Output Voltages: 3.3V, 5.1V, 12V, 15V, ±5V, ±12V, ±15V
- Output Current: up to 2.5A (depends on model)
- Efficiency: up to 89%
- Isolation Voltage: 1500 VDC
- Isolation Capacitance: less than 2000 pF
- Temperature Range: -40°C to +80°C (up to +85°C with heat sink)
- Switching Frequency: 300 kHz
- Ripple & Noise: 80-100 mVp-p
- Protection: Short circuit and overvoltage
- Physical: 1" x 1" shielded metal case with baseplate
- Safety: UL/cUL 60950-1, IEC/EN 60950-1
- MTBF: approx. 2.6 million hours
- Soldering Temperature: max +260°C for 10 seconds
Buy the Buy TracoPower 10W DC/DC Converter Part Number THL102412 Online
Secure your power management solution by purchasing the TracoPower THL102412 online today. This efficient 10W converter offers wide input voltage support, high isolation, and excellent thermal performance. Its compact design fits seamlessly into industrial electronics, instrumentation, and communication systems. With a protective metal shield, robust safety standards, and a 3-year warranty, this converter ensures reliability, safety, and long-term operation. Order now to enhance your project with a dependable power conversion module that delivers optimal performance and compatibility for demanding applications.
Buy TracoPower THL102412 now and experience reliable, high-efficiency power conversion for industrial and instrumentation applications.
