TRACO POWER THL154815WI DC/DC Converter
The THL 15WI series is a compact, 15 Watt DC/DC converter with a metal 1” x 1” x 0.4” enclosure, designed for high efficiency up to 91%. It features an ultra wide 4:1 input voltage range (9-36V and 18-75V), operates from -40°C to +70°C without derating, and includes internal EMI filters meeting EN 55032 class A standards. Suitable for industrial, communication, and instrumentation applications, it provides isolated outputs, remote On/Off, and overload, overvoltage protections, making it an ideal solution for distributed power architectures and mobile equipment.
TRACO POWER THL154815WI DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC and 18-75 VDC
- Output Power: 15 Watt
- Efficiency: Up to 91%
- Operating Temperature: -40°C to +70°C without derating
- Isolation Voltage: 1500 VDC input to output
- Protection: Overload, overvoltage, short circuit
- Size: 1" x 1" x 0.4" metal package
- Filter: Internal EN 55032 class A EMI filter
- Remote On/Off: Yes
- Dimensions: Length 25.4 mm, Width 25.4 mm, Height 10.16 mm
- Switching Frequency: 310-385 kHz
- Case Material: Aluminium alloy with black anodized coating
- Soldering Temp: Max. 260°C for 10 sec
- MTBF: 1,374,700 hours
- Certifications: IEC/EN 62368-1, UL 62368-1
- Temperature Range: -40°C to +70°C operating, max +105°C case temperature
Buy the Buy Traco Power THL 15WI Part Number THL154815WI Online
Enhance your electronics with the Traco Power THL 15WI series, a reliable 15 Watt DC/DC converter designed for wide input voltage ranges and high efficiency. Its compact metal package, industrial-grade protections, and EMI filtering make it perfect for communication, instrumentation, and distributed power applications. With features like remote On/Off, overload, overvoltage, and short circuit protections, it offers versatile and safe power supply solutions. Purchase online today to streamline your design process with this high-performance, cost-effective power conversion module.
Order your Traco Power SeriesTHL 15WI THL154815WI today and ensure reliable, efficient power conversion for your industrial and communication projects.
