TRACO POWER TPP450148M Medical Power Supply
The TPP 450 Series is a high-efficiency, 450 Watt medical power supply designed for demanding healthcare applications. Featuring a compact 3" x 5" enclosure, it offers fanless operation at up to 320W and can handle up to 450W with a fan at higher temperatures. It complies with IEC/EN/ES 60601-1 standards for medical safety, including reinforced isolation and low leakage current suitable for BF applications. The power supply provides stable output voltages, extensive protections, and optional auxiliary outputs, making it ideal for medical devices requiring reliable, space-saving power solutions.
TRACO POWER TPP450148M Medical Power Supply Specifications:
- Input Voltage Range: 85–264 VAC with 4/7–63 Hz frequency
- DC Input Range: 120–370 VDC, derating at low input voltages
- Output Power: 450 Watt, with 12 V, 15 V, 24 V, 36 V, 48 V options
- Output Current: up to 375A on certain models, with ±8% adjustment
- Efficiency: up to 94%, low power consumption at no load (0.4–0.8W)
- Isolation Voltage: 4000 VAC input to output, 2500 VAC input to ground
- Temperature Range: -40°C to +80°C, derated at high temperatures
- Protection: overvoltage, overload, short circuit, and overtemperature protections
- Certifications: IEC/EN/ES 60601-1, UL 62368-1, EMI compliant as per EN 55032
- Dimensions: 3" x 5" x 1.3" (76 x 127 x 33 mm), weight approximately 552g
- Additional Features: standby 5V/2000mA, remote on/off control, power good signal
- Altitude: operational up to 5000 meters
- Operating humidity: 5–95% RH non-condensing
Buy the Buy TracoPower TPP450148M Part Number 450 Watt Medical Power Supply Online
Purchase the TracoPower TPP450148M online today to ensure a reliable power source for your medical devices. This 450Wcertified power supply features high efficiency up to 94%, fanless operation up to 50°C, and extensive safety protections including reinforced isolation according to IEC/EN/ES 60601-1 standards. Its compact 3" x 5" enclosure fits in space-constrained environments, making it ideal for demanding healthcare applications. Enjoy fast delivery, quality assurance, and long-lasting durability with every order—trusted for critical medical needs.
Get TracoPower TPP450148M today—compact, fanless, and certified safe for medical devices.
Frequently Asked Questions
Where can I buy TRACO POWER TPP450148M?
You can click on the BUY or RFQ button to purchase TPP450148M from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP450148M?
You can download the TPP450148M datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP450148M?
TRACO POWER
