TRACO POWER THL62422WISM DC/DC Converter
The THL 6WISM series from TracoPower comprises 6W single and dual output DC/DC converters in SMD packages. These compact converters feature fully regulated outputs with an ultra-wide 4:1 input voltage range, making them suitable for various applications. They include an internal filter that meets EN55022 Class A standards without external components, simplifying design integration. Additional features include remote on/off control, short circuit protection, high efficiency up to 83%, and a switching frequency of 330 kHz. The converters provide an I/O isolation voltage of 1500VDC (60 seconds), with an isolation capacitance of 1500pF and resistance greater than 1 GΩ at 500VDC. Ripple and noise are limited to 100 mVp-p (20 MHz bandwidth). Their dimensions are 20.3mm x 10.5mm x 22mm (W x H x D). They conform to UL/cUL 60950-1 and IEC/EN 60950-1 safety standards and come with a 3-year warranty. Operating temperature ranges from -40°C to +75°C under natural convection cooling.
TRACO POWER THL62422WISM DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC
- Output Voltage: 5VDC
- Output Current Max.: 600 mA
- Efficiency: Up to 83%
- Isolation Voltage: 1500 VDC for 60 seconds
- Isolation Capacitance: 1500 pF
- Isolation Resistance: >1 GΩ at 500 VDC
- Ripple and Noise: 100 mVp-p (20 MHz bandwidth)
- Switching Frequency: 330 kHz
- Operating Temperature: -40°C to +75°C
- Dimensions: 20.3mm x 10.5mm x 22mm
- Material: Non-conductive UL94V-0 plastic casing
- Weight: 78 g
- Safety Standard: IEC 60950-1, UL 60950-1
- Altitude: up to 51,000 m
- Humidity: 95% non-condensing
Buy the TracoPower Series THL 6WISM DC/DC Converter: THL62422WISM
Purchase the TracoPower THL62422WISM DC/DC converter online today and enjoy a reliable power solution with an ultra-wide input range, regulated outputs, internal filters meeting EN55022 Class A standards, remote On/Off control, and high efficiency up to 83%. Compact and designed for industrial, telecom, and instrumentation use, it features excellent isolation of 1500VDC, operating temperature from -40°C to +75°C, and a 3-year warranty. Easy to integrate, it ensures stable power with low ripple and noise, making it an ideal choice for demanding electronic applications.
Get TracoPower THL62422WISM today—built for precision, high efficiency, and long-lasting durability.
