TRACO POWER THM100512 Medical Power Converter
The THM 10WI series comprises medical-grade 10 Watt DC/DC converters housed in a compact DIP-24 plastic case. Featuring ultra-wide 4:1 input voltage range, reinforced isolation of 5000 VACrms, and low leakage current below 2 µA, these converters are certified for IEC/EN/ES 60601-1 3rd edition for 2x MOPP safety standards. They operate reliably from -40°C to +90°C, have high efficiency up to 87%, and include features like overcurrent and overvoltage protection, making them ideal for medical, transportation, and measurement applications with extended operating temperature and high altitude endurance.
TRACO POWER THM100512 Medical Power Converter Specifications:
- Input Voltage Range: 3.3VDC to 48VDC, 4:1 wide input ratio
- Output Voltage Options: 3.3 V, 5 V, 12 V, 15 V, 24 V, 36 V, 48 V
- Maximum Output Current: 2.5 A for 3.3V, 2 A for 5V, 830 mA for 12V, 670 mA for 15V, 416 mA for 24V, 75 mA for 36V, 416 mA for 48V
- Efficiency: Up to 87%
- Isolation Voltage: 5000 VACrms, rated for 250 VAC working voltage
- Operating Temperature: -40°C to +90°C with derating above 75°C
- Humidity: 5% to 95% RH non-condensing
- Dimensions: Compact DIP-24 plastic case, typical size approximately 23.22 mm x 14 mm
- Leakage Current: Less than 2 μA
- Certifications: IEC/EN/ES 60601-1 3rd edition, IEC 60601-1-2 4th edition, UL, EN 55032 class A
- Protection: Overcurrent, Overvoltage, Short Circuit, and Overtemperature
- Mechanical: Non-conductive black plastic casing, silicone potting, maximum soldering temperature 265°C for 10 seconds
- MTBF: Approximately 3,850,000 hours
Buy the Buy Traco Power DC/DC Converter Part Number THM100512 Online
Purchase the Traco Power THM100512 online today for a highly reliable 10-watt medical-grade DC/DC converter. It offers ultra-wide input voltage, reinforced 5000 VACrms isolation, low leakage current, and high efficiency up to 87%. Designed to operate from -40°C to +90°C with certification for IEC 60601-1 standards, making it suitable for medical, transportation, and measurement applications. Its compact DIP-24 case, robust protection features, and extended operational altitude up to 5000 meters ensure optimal performance in demanding environments, delivering consistent power with safety and compliance assurance.
Buy Traco Power THM100512 now and experience unmatched reliability and performance in medical-grade power conversion solutions.
Frequently Asked Questions
Where can I buy TRACO POWER THM100512?
You can click on the BUY or RFQ button to purchase THM100512 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM100512?
You can download the THM100512 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM100512?
TRACO POWER
